| After-sales Service Provided: | Overseas third-party support available |
|---|---|
| Warranty: | 2 years |
| Brand Name: | VINER |
| Usage: | Heat Treatment Furnace |
| Condition: | New |
| Certification: | CE, ISO9001 |
| Model Number: | VN-VF1800 |
| Place of Origin: | China (Mainland) |
| Type: | Resistance Furnace |
| Max temperature: | 1800C |
| Controlling Accuracy: | +/-1C |
| Heating Elements: | super 1900 MoSi2 Heating Element |
Quick Details
Specifications
Is the most cost effective bench-top high temperature muffle furnace. the furnace consists of high quality alumina fiber brick and MoSi2 heating elements with chamber of 24"x24"x24", and Temperature is controlled by high precision digital controller with accuracy +/-1.C and 51 segments programmable up to 1800C or 3092F. It is an ideal tool for materials annealing and sintering in your research laboratory.
VINER Industrial Vacuum Furnace Specifications:
Item |
VINER Industrial Vacuum furnace | |||
Max. Temperature |
1200 (<3hour) |
1400C (<3hour) |
1800C (<1hour) | |
Working temperature |
1100C |
1300C |
1600-1700C | |
Vacuum degree |
100Pa, 10Pa, 1Pa, 10*-1pa, 10*-3pa optional | |||
Working atmosphere |
Vacuum, Nitrogen, Argon etc. Inert gas | |||
Temperature accuracy |
±1C | |||
Heating rate |
0-20C/min | |||
Thermocouple |
K type |
S type |
B type | |
Heating element |
Resistance wire |
SiC heating element |
MoSi2 heating element | |
Furnace structure |
Double layer steel casing with dual cooling fan, Surface temperature below 60C | |||
Stander chamber size (mm) 100x100x100 120x120x130 150x150x150 150x150x200 200x200x200 200x200x300 250x250x300 300x300x300 300x300x400 350x350x500 400x400x400 450x450x450 500x500x500 600x600x600 800x800x800 900x900x900 Note: the chamber size can be customized
VINER Industrial Vacuum
Furnace Standard Sizes:
Note: the
above are standard sizes with semi-finished in stock, other sizes customized
VINER Industrial Vacuum Furnace Package:
Polyfoam Filled, Wooden Box Outside
VINER IndustrialVacuum FurnaceWarranty:
Our furnaces Are warranted to be free from defects in materials or workmanship for 2 years from the date of purchase.
Within this Period, across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the Customer for parts, provided that the customer shall be responsible for any Transportation cost. this warranty does not cover consumables and failures due To abuse, misuse, accident or unauthorized alteration or repairs.
VINER Industrial Vacuum Furnace Shipping:
VINER Industrial could supply you the follow shipping way for your choice:
--by DHL/Fedex (Door to door, Home delivery service)
--by Air to Your nearest Airport
--by Sea to Your nearest Seaport
--by the Sellers' shipping agent
Company Information:
VINER Industrial Specializes in different sizes and kinds of high temperature furnaces including Muffle Furnace, Vacuum Tube furnace, Vertical Tube Furnace, Rotary Tube furnace, Crucible furnace, Vacuum furnace, Atmosphere Furnace, Bottom Loading furnace, and Vacuum Drying Oven, the chamber sizes Could be according to customers' design.
Also, VINER Industrial produces and supplies high Temperature Kiln Furnace Spare Parts including MoSi2/SiC/Resistance Wire heating elements, Ceramic Fiber Insulation, Alumina/Zirconia Ceramics, Silicon Carbide Ceramics, Boron Nitride (BN) Ceramics, Vacuum Flanges, Thermocouple, PID Temperature Controller, and Quartz Furnace Tube. Ps kindly inquiry us, we will try our best to serve you.
Welcome to visit manufacture line!!
