| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | JUNENG |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 CE |
| Weight: | 4.5ton |
| Dimension(L*W*H): | 3*2*2.1 |
| Power(W): | 7.5kw |
| Voltage: | 3 phase, 380v |
| Model Number: | JN2S2L |
| Place of Origin: | China (Mainland) |
| Application: | Bottle |
| Volume: | MAX.2L |
| Dry cycle: | 800*2 |
| Clamping force: | 38kn |
| Out of HDPE: | 50-60kg/hr |
| oil pump of driver motor: | 7.5 |
| mould stroke: | 138-368mm |
| size of mould: | 300*320 |
| air volume: | 0.4 |
| blowing pressure: | 0.6-0.8mpa |
| water consumption: | 50 |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
Max. Product Volume
L
JN-2S2L Dry cycle
PC/H
800*2 Screw diameter
MM
60 Screw L/D ratio
L/D
24-26 Screw motor power
KW
15 Screw heating capacity
KW
3.3*4.5 No. of heating zone
Zone
3 Output of HDPE
KG/H
50-70 Oil pump driver power
KW
7.5 Clamping force
KN
38 Mold stroke
MM
138-368 Size of mold(W*H)
MM
300*320 Moving distance
MM
370 Max. Die diameter(W*H)
MM
90 Die heat capacity
KW
1.8-3.5 Blowing pressure
MPA
0.6-0.8 Air volume
M3/Min
0.4 Cooling water pressure
MPA
0.3 Water consumption
L/Min
50 Weight of machine
Ton
4.5 Size of machine
M
3*2*2.1
3.Performance features:
