| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | JUNENG |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 CE |
| Weight: | 16ton |
| Dimension(L*W*H): | 5.4*2.2*4.5 |
| Power(W): | 45 |
| Voltage: | 3 phase, 380v |
| Model Number: | JN-S80L |
| Place of Origin: | China (Mainland) |
| Application: | Bottle |
| Volume: | 80L |
| Dry cycle: | 360 |
| Clamping force: | 300kn |
| Out of HDPE: | 180-220 |
| oil pump of driver motor: | 45kw |
| mould stroke: | 500-1200 |
| size of mould: | 800*1000 |
| die heat capacity: | 12.8kw |
| blowing pressure: | 0.8mpa |
| water consumption: | 100L/min |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
Max. Product Volume
L
JN-S80L Dry cycle
PC/H
360 Screw diameter
MM
100 Screw L/D ratio
L/D
24-26 Screw motor power
KW
45-55 Screw heating capacity
KW
8.4-10.5 No. of heating zone
Zone
4-5 Output of HDPE
KG/H
180-220 Oil pump driver power
KW
37 Clamping force
KN
300 Mold stroke
MM
500-1200 Size of mold(W*H)
MM
800*1000 Moving distance
MM
420 Max. Die diameter(W*H)
MM
9.2 Die heat capacity
KW
12.8 Blowing pressure
MPA
0.8 Air volume
M3/Min
1.2 Cooling water pressure
MPA
0.3 Water consumption
L/Min
100 Weight of machine
Ton
16 Size of machine
M
5.4*2.2*4.5
3.Performance features:
