Product Description

Gas waste heat exchanger mainly consists of heat exchange tube bundle and bellows.the heat exchange tube bundle is composed of H-shaped finned tube, tube box, inlet and outlet tube, side beam, u-shaped bent tube segment, bundle support beam and so on.the bellows have a tapered variable diameter transition structure and an internal gas deflector.

Product Picture





Technical Parameters

Reasonable metal-wall temperature and material corrossion resistant is selected  when design.

ND steel (09CrCuSb) - the most ideal steel at home and abroad"sulfuric acid resistance low temperature dew point corrosion"

Reasonable gas flow rate is selected.

Anti-abrasion device is adopted.

H-type finned tube is adopted to expand heat area.



Product Feature

Sealed and reliable for recycled operation; anti-leakage, not easy to jam; convenient and quick maintenance  & cleaning.



Product Advantage

Lower costs for maintenance,widely used in heating, electricity, metallurgy, petrochemical, air conditioning and other industries.
