Product Description

the plate and frame heat exchanger belongs to welded plate heat exchanger, plate is the core element of heat transfer, with the advantages of plate heat exchanger, high heat transfer efficiency, compact structure, high temperature resistance, good sealing performance, safety and reliability etc. Suitable for conditions like gas-gas, vapor (gas) liquid and liquid-liquid, especially suitable for heat transfer needs of plate heat exchangers under high temperature and high pressure etc special media limitation.the reasonable process setting makes sure of  heat transfer efficiency and resistance loss.

Product Picture





Technical Parameters

Design pressure: P≤3.0MPa

Max.Bearing capacity≤3.75MPa

Design temperature: -70~300°C

Max. Heat transfer area of single machine  :1600m2

Plate thickness: 0.7~1.0mm



Product Feature

Compact structure, small space, more compact than plate heat exchanger, the heat transfer area of 130m2Can be achieved within 1m3. Easy to maintain, clean and assemble, easy to find and identify problems.



Product Advantage

Plate as a heat transfer element has the same heat transfer coefficient and heat transfer efficiency as plate heat exchanger. with strong adaptability in working conditions, the flow combination can be set flexibly according to different process requirements to achieve reasonable matching of heat transfer efficiency and resistance loss. Compared with the detachable plate heat exchanger, the heat and pressure resistance is stronger, suitable for special media.the influence and corrosion of seal gasket under high temperature and special medium conditions are eliminated, and improving the using temperature, pressure and suitable media.
