Parameters

Unit

Value

Center Wavelength

nm

1064

Operating Wavelength Range

nm

±5

Typ. Peak Isolation at 23℃

dB

35

Min.Isolation at 23℃

dB

28

Max. Insertion Loss at 23℃

dB

1.7

Max. Insertion Loss at 23℃ and Input Power 300 mW

dB

2.0

Max. Insertion Loss at 23℃ and Input Power 1 W

dB

2.5

Max. Insertion Loss at 23℃ and Input Power 2 W

dB

3.0

Max. Polarization Dependent Loss at 23℃, only for PI

dB

0.2

Min. Extinction Ratioat 23℃, only for PM

dB

20

Min. Return Loss(Input /Output)

dB

45

Max.AverageOptical Power

W

2

Max. Peak Power for ns Pulse

kW

10

Max. Tensile Load

N

5

Operating Temperature

℃

+10 to +50

Storage Temperature

℃

0 to +60
