| Brand Name: | RUIK |
|---|---|
| MOV: | RUIK |
| thermal fuse: | RUIK |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Parameters |
Unit |
Value |
Center Wavelength |
nm |
1064 or 1030 or 980 or 915 or 850 or 780 |
Operating Wavelength Range |
nm |
±5 |
Typ. Peak Isolation at 23℃ |
dB |
65 |
Min.Isolation at 23℃ |
dB |
55 |
Typ. Insertion Loss at 23℃ |
dB |
0.8 |
Max. Insertion Loss at 23℃ |
dB |
1.2 |
Max. Polarization Dependent Loss at 23℃,Only for PI |
dB |
0.2 |
Min. Extinction Ratio at 23℃, only for PM |
dB |
20 |
Min. Return Loss(Input /Output) |
dB |
45 |
Max.AverageOptical Power |
W |
20 or Specified |
Max. Peak Power for ns Pulse |
kW |
10 or Specified |
Max. Tensile Load |
N |
5 |
Package Dimension |
mm |
150x28x26 |
Operating Temperature |
℃ |
+10~+50 |
Storage Temperature |
℃ |
0~+60 |
High power Optical Fiber Components:
-Optical Fiber Isolator, up 100W;
-Free Space Isolator, up to 100W;
-Optical Circulator, up to 30W;
-Pump Laser Protector;
-Band Pass Filter;
-Nx1 Pump Combiner;
-Cladding Power Stripper;
-Mode Field Adapter;
-(N+1)x1 Pump & Signal Combiner, 200W/port;
Polarization Maintaining Fiber Components:
-in Line Polarizer/Depolarizer;
-in Line Faraday Isolator;
-Optical Circulator;
-Fused WDM / Coupler;
-Filter WDM / Coupler;
-Fiber DWDM
-Fiber Mirror;
-Faraday Rotator;
-Fiber Patch cord / Jumper;
-PLC Splitter Module;
-Tap / WDM / Isolator Hybrid;
Manual Variable Optical Attenuator;
-1x2 Polarization Beam Splitter / Combiner (PBS/C)
-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)
