Quick Details

Brand Name:	RUIK
MOV:	RUIK
thermal fuse:	RUIK
Model Number:	RUIK-PMJ
Place of Origin:	China (Mainland)

Specifications

Parameter		Unit	Value
Connector Type		-	FC, SC,LC/,MU FC/APC, SC/APC,LC/APC
Center Wavelength		nm	1310/1550	980/1060	850	780
Max. Insertion Loss		nm	0.3	0.5	0.8	0.8
Min. Extinction Ratio at 23℃		dB	23	23	22	22
Min. Return loss	UPC Type	dB	50
	APC Type	dB	60
Fiber Type		-	PM Panda fiber
Key Orientation		-	Slow Axis
Tolerance forAxis Alignment		deg	±3
Operating Temperature		℃	-20~+70
Storage Temperature		℃	-40~+85

Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm. We also provide Customized components to our customers.

High power Optical Fiber Components:
-Optical Fiber Isolator, up 100W;
-Free Space Isolator, up to 100W;
-Optical Circulator, up to 30W;
-Pump Laser Protector;
-Band Pass Filter;
-Nx1 Pump Combiner;
-Cladding Power Stripper;
-Mode Field Adapter;
-(N+1)x1 Pump &amp; Signal Combiner, 200W/port;
Polarization Maintaining Fiber Components:
-in Line Polarizer/Depolarizer;
-in Line Faraday Isolator;
-Optical Circulator;
-Fused WDM / Coupler;
-Filter WDM / Coupler;
-Fiber DWDM
-Fiber Mirror;
-Faraday Rotator;
-Fiber Patch cord / Jumper;
-PLC Splitter Module;
-Tap / WDM / Isolator Hybrid;
Manual Variable Optical Attenuator;
-1x2 Polarization Beam Splitter / Combiner (PBS/C)
-1x2 Isolator &amp; Polarization Beam Splitter / Combiner (IPBS/C)
