| Brand Name: | YRT |
|---|---|
| Wavelength: | 1320 |
| Data Rate: | 300 |
| warranty: | 12month |
| Connector: | sc/st/fc/lc |
| Model Number: | MM |
| Place of Origin: | China (Mainland) |
| Type: | Optical Fibers, Custom |
| Material: | PVC |
| Fiber Diameter: | 3.0mm |
| Model Number: | optic fiber patch cord |
| Use: | FTTH |
| Color: | Custom |
| Application: | Network |
Quick Details
Specifications
Singlemode patch cord
ITEM: Single mode patch cord(simplex/duplex)
Fiber type: SM(G652/G657A)
Jacket material: LSZH/PVC
Connector type: SC/FC/LC/ST
Specification
Item |
Single mode patch cord(simplex/duplex) |
Fiber type |
SM(G652/G657A) |
Jacket material |
LSZH/PVC |
Connector type |
SC/FC/LC/ST |
Ferrule materials |
Ceramic APC /UPC |
Cable dimension |
0.9mm,2.0mm,3.0mm |
Cable color |
Yellow |
Testing wavelengths |
1310±30/1550±30nm |
Insertion Loss(dB) |
≤ 0.3dB |
Return Loss(dB) |
≥50dB |
Operating Temperature (° C) |
-10~ + 70 |
Storage Temperature (° C) |
-40 ~ +85 |
Package |
Poly bag |
Feature
01Low insertion loss
02Good reproducibility
03High return loss/p>
04Good mutual insert performance
05Good temperature stability
