| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 12 months |
| Brand Name: | Rongtai |
| Usage: | Billet Heating |
| Condition: | New |
| Certification: | CE |
| Power(W): | 100kW - 6000kW |
| Voltage: | Customized |
| Model Number: | GT |
| Place of Origin: | China (Mainland) |
| Type: | Induction Furnace |
Quick Details
Specifications
Higher stability: Using the latest generation of digital control circuit technology, coupled with Rongtai's latest eighth-generation main control circuit board, greatly improving the stability of equipment operation.
Lower power consumption: Thanks to Rongtai's rich experience in series resonance technology and research and development in the field of induction heating equipment, series resonance technology has been stably and widely used in the field of induction heating, greatly reducing the power consumption of induction heating equipment.
Forging automation: Optional automatic feeding system, material temperature monitoring and sorting system, remote monitoring and control system, with real-time data input and output of Rongtai intelligent forging system, can realize the connection with upstream and downstream supporting equipment and factory production process Execute system (MES) access to achieve automate, intelligent and unmanned forging plants.
| Power Ranges | 120KW-8,000KW |
| 200Hz-10,000Hz | |
| Power Factor ≥ 0.99 | |
| Contact Rongtai for Custom Solutions | |
| Round Bar Size | 18*18~180*180mm, Length ≥20mm |
| Applications | Forging, Rolling, Extrusion, online Heating and Post Heating of Continuous Casting Process |
| Standard Features | Rongtai Eighth Generation Master Control Board |
| 6, 12 or 24 Pulse Line Power Rectifier System | |
| Water pressure and temperature automatic detection system | |
| Adjustable Power Control for all power levels, Manual or Automatic | |
| Optional Features | Smart Control System |
| Digital control board with clear fiber optic signal processing | |
| Data input and output interface for automation connection | |
| Workpiecel temperature monitoring and sorting system | |
| Automatic Workpiece Loading and Feeding System | |
| Remote monitoring and MES access | |
| Inductor Coil Fast Switching Device in Double Station | |
| Factory Tested | Power Supply Unit, No-load Test, Critical Components etc. |
