Quick Details

Brand Name: BL
Interface Type: RS-232
Type: Wireless
Style: External
Products Status: Stock
Place of Origin: China (Mainland)
Model Number: G6
Certification: CE ROHS
Transmission Rate: 128Kbps
Interface: USB RS232
Application: M2M wireless POS, smart metering, tracking, etc
Feature: 4G NB-IOT

Specifications

BG96 is a series of LTE Cat.M1/Cat.NB1/EGPRS module offering a maximum data rate of 375kbps downlink and uplink. It features ultra-low power consumption, and provides pin-to-pin compatibility with Quectel LTE module EG91/EG95, Cat.NB1 (NB-IoT) module BC95, UMTS/HSPA module UG95/UG96 and GSM/GPRS module M95.





Quectel BG96

LTE Cat.M1&Cat.NB1& EGPRS Module



Variant for North America



BG96-NA



Cat.M1/Cat.NB1:



LTE FDD: B2/B4/B12/B13



Variant for the Global

BG96

Cat.M1/Cat.NB1:

LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13

/B18/ B19/B20/B26/B28

   LTE TDD: B39 (for Cat.M1 Only)

EGPRS:

850/900/1800/1900MHz



Module DETAILS:

Data

Cat.M1:
Max. 375Kbps (DL), Max. 375Kbps (UL)
Cat.NB1:
Max. 32Kbps (DL), Max. 70Kbps (UL)
GPRS:
Max. 107Kbps (DL), Max. 85.6Kbps (UL)
EDGE:
Max. 296Kbps (DL), Max. 236.8Kbps (UL)

Voice

 VoLTE (for Cat. M1 Only. Support Realtek ALC
5616 Codec by Default Firmware)
SMS

Point-to-point MO and MT

SMS Cell Broadcast

Text and PDU Mode

Enhanced Features

GNSS (Optional):

GPS, GLONASS, BeiDou/Compass, Galileo, QZSS

Firmware Upgrade:

Via USB interface

DFOTA:

Delta Firmware Upgrade over the Air

Electrical Characteristics

Output Power:

Max. Power: 23dBm

Consumption (Typical):

LTE Cat.M1 Mode:

Power Saving Mode: 10.4uA

Standby State: 1.99mA @DRX=1.28s

LTE Connected Mode:

124mA @0dBm

136mA @12dBm

190mA @23dBm

LTE Cat. NB1 Mode:

Power Saving Mode: 9.8uA

Standby State: 2.77mA @e-I-DRX=20.48s

LTE Connected Mode: TBD

Software

USB Driver:
Windows XP, Windows Vista,
Windows 7/8/8.1/10, Windows CE 5.0/6.0/7.0,
Linux 2.6/3.x/4.1, Android 4.x/5.x/6.0
RIL Driver: Android 4.x/5.x/6.0
NDIS Driver: Windows 7/8/8.1/10
ECM* Driver: Linux 2.6/3.x/4.1
Gobinet Driver: Linux 2.6/3.x/4.1
QMI_WWAN Driver: Linux 3.x(3.4 or later)/4.1

Protocols: PPP/TCP/UDP/SSL/TLS/FTP(S)/HTTP(S)

General Features

3GPP E-UTRA Release 13
Temperature Range: -40°C ~ +85°C
Dimensions: 22.5mm 26.5mm 2.3mm
Approx. 3.1g
LGA Package
Supply Voltage: 3.3V~4.3V, 3.8V Typ.
3GPP TS27.007, 3GPP TS 27.005 and Quectel
Enhanced at Commands
