| Use: | Truck Trailer |
|---|---|
| Brand Name: | ChinaTrailers |
| Max Payload: | 45 tons per axle line |
| Size: | 9000*2990*1175 |
| Material: | Steel |
| Use: | heavy transportation |
| Model Number: | SY-V3 |
| Place of Origin: | China (Mainland) |
| OEM No.: | Customized |
| Type: | Semi-Trailer |
| Wheelbase: | 1500mm |
| Trend: | 1800/735mm |
| Suspension: | All wheels hydraulic suspension |
| Steering: | All wheels hydraulic steering |
| Payload: | 45 tons per axle line |
| Size: | Customized |
Quick Details
Specifications
Goldhofer THP/SL Conventional Modular Trailer
Conventional modular trailer is specialized for heavy load transportation, featured with strong structure and high loading ability.
Manufacturer, ChinaTrailers, brings in core technologies from German Goldhofer and makes some improvements to meet various clients need.
ChinaTrailers model SY-V3 uses Italy Lombardini engine and imported spare parts. It can be fully coupled with German Goldhofer THP/SL.
Main Parts We Use as below: Cylinder HAITE (CHINA)
Material
Q690E high-strength steel Hydraulic Sealing Parts
PARKER (USA) 5 Joints Multi Way Valve
BONDIOLO& PAVESI (ITALY) Stop Valve
STAUFF (GERMAN) Tyre 215/75R17.5
DOUBLE COIN (CHINA) Hydraulic Hose
AEROQUIP (GERMAN) Quick Coupling
VOSWINKEL (GERMAN) Slew Bearing
ROTHE ERDE (GERMAN)
Main Technical Features as below:
Wheelbase
1500mm Trend
1800/735mm Minimum ground clearance
148mm Height of platform
1175± 300mm Suspension
Hydraulic suspension Support mode of platform
3 and 4 points suspension Payload per axle line
22.5tons @ 18km/h Max capacity per axle line
45tons
Loading Test Before Shipping:
Comprehensive after Sale Service:
7-10 days to your site to teach your staffs to operate the use of modular FREE.
