1. High efficiency and energy saving: the unit adopts world's famous brand compressor as well as special for heat pump,uses environmentally friendly refrigerant and high efficiency heat exchanger, works in accordance with heat pump control technology. with the help of a special proprietary high temperature heating system, which is more stable than usual, the unit provide high thermal efficiency in high temperature drying(80-85℃) process, meanwhile, energy is significantly conserved, and the cost of producing thermal is much lower than electric heating, gas and fuel.

2. Green and environmentally friendly: high -temperature hot water can be used as a heat medium, and the required baking materials are baked by the heat pump drying equipment. the.Unit eliminates the pollution of waste gas and waste residue generated bu combustion.





There are 5 models of the product.



ENE-13KDH/ ENE-26KDH/ENE-26KCH/ENE-32KCH/ENE-60KCH



Application environment range(℃)  -7~43

Nominal heating capacity(KW)      13.8

Nominal heating input power(KW0  4.29

Protection level                  IPX4

Weights(KG)   115

Dimensions   750*690*1050

Applicable drying room volume(m3) 15



Application environment range(℃)  -7~43

Nominal heating capacity(KW)      26.8

Nominal heating input power(KW0  9

Protection level                  IPX4

Weights(KG)   230

Dimensions   1500*690*1070

Applicable drying room volume(m3) 30



Application environment range(℃)  -7~43

Nominal heating capacity(KW)      26

Nominal heating input power(KW0  8.67

Protection level                  IPX4

Weights(KG)   230

Dimensions   1720*1060*1100

Applicable drying room volume(m3)  30







Application environment range(℃)  -7~43

Nominal heating capacity(KW)      32

Nominal heating input power(KW0  10.67

Protection level                  IPX4

Weights(KG)   300

Dimensions   1720*1060*1100

Applicable drying room volume(m3)  38



Application environment range(℃)  -7~43

Nominal heating capacity(KW)      60

Nominal heating input power(KW0  20

Protection level                  IPX4

Weights(KG)   600

Dimensions   2100*1100*2000

Applicable drying room volume(m3)  76
