Power supply	/	380 3N/50Hz
Refrigerating capacity	KW	181	227	247	314	341	401	451	517	616	721	760	826
Rated power	KW	41	50	53	70	76	86	97	111	129	153	160	177
Rated current	A	73	90	97	121	135	152	171	197	231	272	292	321
Performance ratio	W/W	4.5	4.6	4.6	4.5	4.5	4.7	4.7	4.7	4.8	4.7	4.8	4.7
Water-carrying capacity	m3/h	31	39	42	54	59	69	78	89	106	124	131	142
Water pipe diameter	mm	100	100	100	100	100	100	100	100	100	100	100	100
Weight	kg	4400	4870	5460	6230	7070	7760	8340	9350	10610	11500	12430	13280
Dimensions	mm	3850*2400*3350	4050*2400*3350	4200*2600*3350	4100*2800*3350	4800*2800*3350	5450*2600*3350	5800*2800*3350	6200*2800*3350	6500*3000*3350	6800*3000*3350	7200*3000*3350	7500*3000*3350
Refrigerant type	/	R134a
Model		ICSE2-360D	ICSE2-460D	ICSE2-500D	ICSE2-630D	ICSE2-680D	ICSE2-800D	ICSE2-900D	ICSE2-1040D	ICSE2-1240D	ICSE2-1440D	ICSE2-1520D	ICSE2-1660D
Power supply	/	380 3N/50Hz
Refrigerating capacity	KW	361	454	494	628	681	803	901	1034	1233	1443	1519	1651
Rated power	KW	83	99	106	138	149	173	193	220	260	306	325	345
Rated current	A	151	180	194	241	265	305	343	391	464	543	595	625
Performance ratio	W/W	4.3	4.6	4.6	4.5	4.6	4.6	4.7	4.7	4.7	4.7	4.7	4.8
Water-carrying capacity	m3/h	62	78	85	108	117	138	155	178	212	248	261	284
Water pipe diameter	mm	125	125	150	150	150	200	200	200	200	250	250	250
Weight	kg	8480	9120	9540	11400	12490	14040	15010	17520	19750	21850	23470	24850
Dimensions	mm	4950*2600*3350	5300*2800*3350	5300*2800*3350	6000*3000*3350	6800*3000*3350	7500*3000*3350	8100*3000*3350	9100*3000*3350	9900*3000*3350	10500*3000*3350	10800*3000*3350	11500*3000*3350
Refrigerant type	/	R134a
Model		ICSB2-195S	ICSB2-220S	ICSB2-250S	ICSB2-315S	ICSB2-340S	ICSB2-385S	ICSB2-470S	ICSB2-540S	ICSB2-620S	ICSB2-700S	ICSB2-760S	ICSB2-845S
Power supply	/	380 3N/50Hz
Refrigerating capacity	KW	190	217	247	309	334	381	464	531	609	692	749	831
Rated power	KW	40	47	55	66	71	79	99	113	127	145	164	181
Rated current	A	77	89	102	117	131	148	178	204	225	265	295	329
Performance ratio	W/W	4.7	4.6	4.5	4.7	4.7	4.8	4.7	4.7	4.8	4.8	4.6	4.6
Water-carrying capacity	m3/h	33	37	42	53	58	65	80	91	105	119	129	143
Water pipe diameter	mm	100	100	100	125	125	125	150	150	150	200	200	200
Weight	kg	4420	4930	5490	6490	7150	7820	9060	9820	11110	11570	15530	13350
Dimensions	mm	3850*2400*3350	4050*2400*3350	4200*2600*3350	4100*2800*3350	4800*2800*3350	5450*2600*3350	5800*2800*3350	6200*2800*3350	6500*3000*3350	6800*3000*3350	7200*3000*3350	7500*3000*3350
Refrigerant type	/	R134a
Model		ICSB2-390D	ICSB2-440D	ICSB2-500D	ICSB2-630D	ICSB2-680D	ICSB2-770D	ICSB2-940D	ICSB2-1080D	ICSB2-1240D	ICSB2-1400D	ICSB2-1520D	ICSB2-1690D
Power supply	/	380 3N/50Hz
Refrigerating capacity	KW	381	433	493	618	669	761	928	1061	1218	1384	1499	1663
Rated power	KW	79	95	105	131	145	169	198	225	248	290	319	347
Rated current	A	151	179	196	232	270	317	357	404	436	528	574	628
Performance ratio	W/W	4.8	4.6	4.7	4.7	4.6	4.5	4.7	4.7	4.9	4.8	4.7	4.8
Water-carrying capacity	m3/h	65	74	85	106	115	131	160	183	210	238	258	280
Water pipe diameter	mm	125	125	150	150	150	200	200	200	200	250	250	250
Weight	kg	8450	9230	9610	11870	12800	14220	16280	18200	20400	21730	23140	25030
Dimensions	mm	4950*2600*3350	5300*2800*3350	5300*2800*3350	6000*3000*3350	6800*3000*3350	7500*3000*3350	8100*3000*3350	9100*3000*3350	9900*3000*3350	10500*3000*3350	10800*3000*3350	11500*3000*3350
Refrigerant type	/	R134a
Product features:   1. Quick installation All component equipment and connection pipes are assembled in the factory and integrated into the overall structure. On-site installation with outdoor rainproof shell, no machine room needed.   2. Short debugging period the operational testing is finished before leaving the factory, reducing on-site debugging time.   3. High efficiency the integrated cooling-water staion including compressor, water pump and cooling fan.Its COP and LPLV are significantly higher than air-cooled and water-cooled machine room system.   4. Stability Equipments are assembled and integrated in the factory to ensure the product safety and stability by pressure,, airtight,electric and performane test.   5. Simple operation Adopts industrial touch tablet as human-computer interface, to monitor and control compresor, water pump, cooling fan and otherinstruments in one interface.   6. Condensation heat recovery(optional) while in the process of refrigeration, up to 60℃ Hot water can be used for heating or sanitary water by heat recovery heat exchanger.   7. Mutiple natual cooling modes(optional)
