Brand Name: | Hiwits |
---|---|
Voltage: | 3.6V |
Measuring Range: | R250 or R500 |
Accuracy Class: | Class 2 |
Display Type: | LCD Screen |
Model Number: | URT-D |
Place of Origin: | China (Mainland) |
Diameter: | DN50~DN300 |
Quick Details
Specifications
Characteristic
High measurement Sensitivity with 4-channel design | |
Using NB-Iot / Rs485 Data remote method as per customer's requirement | |
Strong Anti-interference ability with non-magnetic data acquisition technology | |
Support Intelligent platform to achieve the function of real-time remote monitoring | |
High protection class of IP67/IP68 and using internal and External equal pressure technology and double-layer glue technology to Isolate circuit, water and steam | |
Allow positive and Negative measurement |
Wide measurement Ranges up to 500 |
Low power Consumption and 10-year battery life |
Great of Capacity data storage |
Technical Data
|
Parameter |
Maximum allowable pressure |
1.6MPa(default) / 2.5MPa |
Working Environment |
-25℃55℃, ≤100%RH |
Temperature rating |
T30(default) / T50 / T70 |
Environmental Classes |
Class O |
Data communication |
NB-Iot/ Rs485 |
Protection class |
IP67/ IP68 |
