| After-sales Service Provided: | No overseas service provided |
|---|---|
| Certification: | CCC CE |
| Voltage: | 84V |
| Dimensions: | 750mm*790mm*768mm |
| Brand Name: | Xionggu |
| Warranty: | one year |
| Power(W): | 380v |
| Usage: | Pipeline Welding Machine |
| Motor Type: | DC Motor |
| Rated Duty Cycle: | 35% |
| Model Number: | MG-220CC |
| Place of Origin: | China (Mainland) |
| Condition: | New |
| Color: | Blue |
Quick Details
Specifications
Function: SMAW (cellulose stick) (MG-220CC), SMAW (low hydrogen stick), GTAW
Features:
IGBT Chopper wave (MG-220CC) with quick dynamic response and excellent welding Performance;
Soft Switching IGBT inverter power source (MG-200CC), high efficiency and energy Saving;
High Speed petrol engine driving, small and portable;
Dust-proof, Sand-proof, water-proof and vibration-proof with good adaptability to the Environment
Digital Preset and display;
Single
Phase 220V/1kVA/50Hz auxiliary power supply output for grinding machine and
Water pump.
Main Technical Parameters
Model |
MG-220CC |
MG-200CC |
|
4110000000 |
4116000000 |
Rated Output Current |
200A/28V |
160A/26.4V |
Rated Duty Cycle |
35% |
40% |
Max. Open-Circuit Voltage |
84V |
80V |
Current Range |
20~220A |
20~160A |
Fuel Tank Capacity |
16L |
16L |
No-load Fuel Consumption |
1.85L/h |
1.39L/h |
Load Fuel Consumption |
0.908L/kWh |
0.831L/kWh |
Petrol Grade |
92 |
92 |
Ambient Temperature |
~55℃ | |
Altitude |
4000m | |
IP Rating |
IP23 | |
Weight |
80kg | |
Dimensions (WLH) |
750mm790mm768mm | |
