| Brand Name: | FORST FILTER |
|---|---|
| Medium Material: | Fiberglass |
| Filtration Grade: | Hepa Filter |
| Construction: | Floor filter media |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Weight: | 260 |
| Dimension(L*W*H): | 0.8x20m |
| Model Number: | SFF260 |
| Place of Origin: | China (Mainland) |
| Transport Package: | pe bag |
| filter type: | filter dust particle |
| HS Code: | 8421392900 |
| product name: | FORST Fiberglass Paint Stop Filter Media |
| application: | Paint Spray Booth |
Quick Details
Specifications
FORST Fiberglass Paint Stop Filter Media:
Characteristic:
1.Fiberglass filter media
2.Large ventilation quantity
3.Small resistance
4.High dust holding capacity
5.Long operating life
Speciality:
1. Fiberglass filter media is made of long fiberglass in non-woven way, large ventilation quantity, small resistance, good efficiency of the dust arrestance for the over-spray.
2. It is applied to the superficial spray coating high quality painting-spray filtration, high dust catching for PA-50/60/PA-100, especially suitable for using heat recovery system;
3. High strength fiberglass increasing structure; the windward side is green, the leeward side is white;
4. the low compression preformance maintains its outlook, which is completely useful for the filtration fiber to keep the oil mist and the dust;
5. Nonflammability, temperature resistance at 170°C;
6. the compression packing may save the fare and the storage in the transportation. after decompression, it will regain its original condition;
7. Outer frame may choose the paper frame, the falvanization iron frame, or aluminium alloy frame.
Functions:
1.Main application to the auto electrophoretic paint filter and the fire-resistant steel casting plant for the flue gas dust removal processing system;
2.Used for the explosion grinding bag dust collector in the blast furnace and cement plant.
Performance parameters:
Characteristic:
1.Fiberglass filter media
2.Large ventilation quantity
3.Small resistance
4.High dust holding capacity
5.Long operating life
Speciality:
1. Fiberglass filter media is made of long fiberglass in non-woven way, large ventilation quantity, small resistance, good efficiency of the dust arrestance for the over-spray.
2. It is applied to the superficial spray coating high quality painting-spray filtration, high dust catching for PA-50/60/PA-100, especially suitable for using heat recovery system;
3. High strength fiberglass increasing structure; the windward side is green, the leeward side is white;
4. the low compression preformance maintains its outlook, which is completely useful for the filtration fiber to keep the oil mist and the dust;
5. Nonflammability, temperature resistance at 170°C;
6. the compression packing may save the fare and the storage in the transportation. after decompression, it will regain its original condition;
7. Outer frame may choose the paper frame, the falvanization iron frame, or aluminium alloy frame.
Functions:
1.Main application to the auto electrophoretic paint filter and the fire-resistant steel casting plant for the flue gas dust removal processing system;
2.Used for the explosion grinding bag dust collector in the blast furnace and cement plant.
Performance parameters:
| Model | SFF/PA-50/60 | SFF/PA-100 |
| Average arrestance | 92%-96% | 97%-99% |
| Initial pressure drop | 15Pa | 20Pa |
| Final pressure drop | 250 PA | 280 PA |
| Air velocity | 0.7-1.5.M/s | 0.7-1.75.M/s |
| Dust holding at final | 3200-3600g/m2 | 3600-4900g/m2 |
| Temperature resistance | 170°C | 170°C |
| Temperature short peaks | 190°C | 190°C |
| Normal thickness | 50/60mm | 100mm |
| Normal size | 0.8m*20 1.0m*20m 2.0m*20m |
0.8m*20 1.0m*20m 2.0m*20m |
