| Brand Name: | Huawei |
|---|---|
| Certification: | CE |
| Function: | LACP,POE,QoS,SNMP,Stackable,VLAN Support |
| Transmission Rate: | 10/100/1000Mbps |
| Products Status: | Stock |
| Place of Origin: | China (Mainland) |
| Model Number: | S5720-52X-PWR-SI-AC |
| Switch Capacity: | 336 Gbit/s |
| Communication Mode: | Full-Duplex & Half-Duplex |
| Product Name: | S5720-52X-PWR-SI-AC managed gigabit switch |
| Condition: | 100% Brand New Sealed |
| Warranty: | 1 Year |
| Model: | S5720-52X-PWR-SI-AC |
| Switching Capacity: | 336 Gbit/s |
| Ports: | 48 Ports |
Quick Details
Specifications
Huawei S5720-52X-PWR-SI-AC is a Layer 3 Ethernet switch. It supports forty-eight Ethernet 10/100/1,000 PoE+ ports and 4 x 10G SFP. It offers double hot-swappable AC/DC power supplies, one AC power module is configured by default.
S5720-52X-PWR-SI-AC Specification
Table 1 shows the Quick Specs.
Product Code |
S5720-52X-PWR-SI-AC |
Downlink Ports |
48 x Ethernet 10/100/1,000 PoE+ ports |
Uplink Interfaces |
4 10 Gig SFP+ |
Forwarding Performance |
132 Mpps |
Switching Capacity |
336 Gbit/s |
Stack |
Supported |
Stack Ports |
GE electrical ports and 10GE SFP+ optical ports on the front panel |
Memory (RAM) |
512 MB |
Flash |
240 MB |
Dimensions (W x D x H) |
44.2 cm x 42 cm x 4.44 cm |
Weight (Kg) |
9.6 Kg |
| S5720-52X-PWR-SI-AC Specification | |
Fixed Port |
48 x Ethernet 10/100/1,000 PoE+ ports 4 10 Gig SFP+ |
MAC address table |
IEEE 802.1d compliance |
MAC address learning and aging | |
Static, dynamic, and blackhole MAC address entries | |
Packet filtering based on source MAC addresses | |
MAC address entries: S5700-SI series - 16K | |
VLAN |
4K VLANs |
Guest VLAN and voice VLAN | |
GVRP | |
MUX VLAN | |
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports | |
1:1 and N:1 VLAN Mapping | |
SuperVLAN(supported by the S5700-SI/S5700-EI/S5700-HI series) | |
Ring protection |
RRPP ring topology and RRPP multi-instance |
Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover | |
SEP | |
ERPS(G.8032)(supported by the S5700-LI/S5700-SI/S5700-EI/S5700-HI series) | |
STP, RSTP, and MSTP | |
BPDU protection, root protection, and loop protection | |
BPDU Tunnel | |
