Description

this Air screen cleaner with gravity table is to remove dust, leaf, light impurity by the air screen. and remove above 90% bad seed, like blighted seed, budding seed, damaged seed, rotten seed, deteriorated seed, moldy seed, injured seed, non-viable seed, seed with black powder sick by the gravity table. Remove the big impurity from the back half screen.

Structure:

this seed cleaner with gravity table includes ultra low speed, no broken elevator, vertical air screen, cyclone dusting system, large gravity table, and vibration classification screen.



Features

1. the seed cleaner with gravity table is to remove dust, chaff, shell and other light impurities, the light material particles like blighted seed, budding seed, damaged seed, rotten seed, deteriorated seed, moldy seed, non-viable seed, seed with black powder sick.
2. the front sieve can remove small impurities, which can reduce the load of gravity table and blockage of small particles.
3. the seed cleaner with gravity table can also remove kinds of light and small impurities

Advantages

1. Combines winnowing, screening and gravity separation with multiple functions.
2. Adopts ultra low speed, no broken elevator, large proportion platform and imported vibration key components, assuring the quality.
3. Simple structure; stable and good quality; High precision;

4. this seed cleaner can be used for various materials.



Specification

Model	TAble Size (mm)	Power  (kw)	Capacity (kg/h)	Weight  (kg)	Overall size    LWH(mm)
5XFZG-25SC	1700  1600	12.3	10000	2300	4200  2300  3800
