| Brand Name: | SANRAY |
|---|---|
| Card type: | 2.4GHz~2.5GHz ISM |
| Communication: | WCDMA 3.75G (HSDPA+ 42.2Mbps, HSUPA+ 11.5Mbps) support WIFI route |
| Dimension: | 209*139*20mm |
| Frequency: | 2.4GHz~2.5GHz ISM |
| Model Number: | P6300A |
| Place of Origin: | China (Mainland) |
| CPU: | QualcommMSM8916, A53, 4 core CPU, 1.2GHz |
| Built-in storage: | 2 GB RAM + 16 GB Flash |
| 2G/3G/4G ROM 16G-W: | yes |
| 2G/3G/4G: | yes |
| Phone SIM card interface: | support,common1.8/3.3V SIM card |
| OS: | Android 5.1 |
| 2D scanner: | Optional |
| OTG: | Support |
Quick Details
Specifications
Product advantage
1. Adopt high-performance UHF RFID chips, read and write distance up to 60
Meters. Multi tag reading up to 800 tags/second
2. with high stability;
3. the protection grade could reach IP67.
4. the large capacity battery, long runs.
5. 1.2 meters fall protection.
6. Touch screen: full toughened capacitive touch screen surface hardness
Greater than 8 h, 400 CD/M2 brightness visible in the sunlight.
Product Technical parameters:
Operating frequency 2.4GHz~2.5GHz ISM
RF power range -30dBm~0.0dBm( adjusted by 32 grade )
Receiving sensitivity -90.0dBm
Reading range: 0~60m (Adjustable depending on different gain
Omni-directional antenna,)
Anti-collision: up to 800 tags read simultaneously
Communication speed:250kbps, 1Mbps, 2Mbps(adjustable)
1. Adopt high-performance UHF RFID chips, read and write distance up to 60
Meters. Multi tag reading up to 800 tags/second
2. with high stability;
3. the protection grade could reach IP67.
4. the large capacity battery, long runs.
5. 1.2 meters fall protection.
6. Touch screen: full toughened capacitive touch screen surface hardness
Greater than 8 h, 400 CD/M2 brightness visible in the sunlight.
Product Technical parameters:
Operating frequency 2.4GHz~2.5GHz ISM
RF power range -30dBm~0.0dBm( adjusted by 32 grade )
Receiving sensitivity -90.0dBm
Reading range: 0~60m (Adjustable depending on different gain
Omni-directional antenna,)
Anti-collision: up to 800 tags read simultaneously
Communication speed:250kbps, 1Mbps, 2Mbps(adjustable)
| Size | 209*139*20mm(LWH) |
| Weight(g): | 590g |
| CPU | QualcommMSM8916, A53, 4 core CPU, 1.2GHz |
| Built-in storage | 2 GB RAM + 16 GB Flash |
| 2G/3G/4G ROM 16G-W | FDD-LTE/TDD-LTE/WCDMA/GSM FDD-LTE:1800/2100/2600 B1/B3/B7 TDD-LTE:B38/B39/B40/B41 B38:2570-2620MHz B39:1880-1920MHz B40:2300-2400MHz B41:2555-2575MHz 2575-2635MHz 2635-2655MHz WCDMA: 850/1900/2100 B1/B2/B5 GSM: 900/1800/1900 B2/B3/B8 |
| 2G/3G/4G | CDMA 1X/EVDO BC0 GSM 850/900/1800MHZ WCDMA B1/B5/B8 TD-SCDMA B34/B39 FDD-LTE:B1/B3/B7 TD-LTE:B38/B39/B40/B4 |
| Phone SIM card interface: | Support,common1.8/3.3V SIM card |
| OS | Android 5.1 |
| Navigation and positioning built-in | GPS Satellite-navigation chips, support A-GPS,EPO |
| RFID | Support functions of uhf RFID, read Range up to 10m |
| 2D scanner | Optional |
| OTG | Support |
| FM radio | Support |
| Bluetooth | BT4.0 (A2DP+EDR) |
| Motion sensor | Support |
| Gravity sensor | Support |
| Geomagnetic sensor | Support |
| Gyro Sensor | Support |
| Trumpet | 20x30 Membrane type speaker unit |
| Network connections | 3G/4G |
| Communication | WCDMA 3.75G (HSDPA+ 42.2Mbps, HSUPA+ 11.5Mbps), support WiFi route sharing |
| EDGE: | Support |
| GPRS | Support |
| WAP | Support |
| WI-FI | Support |
| Main display | 7.0" HD IPS/AFFS display 1024 * 600 600 CD/m2 visual highlight the sun. |
| Touch screen | G + G 5 full toughened high strength Capacitance touch screen |
| Main camera | 5 million pixels with af and electronic Flash |
| Deputy camera | 2 million megapixel camera |
| External memory expansion | Micro SD card (T - FLASH card) card Reader, maximum support 64 GB Extension |
| Battery | 7200 mAh |
| Charging interface | USB Micro 5 pin |
| Data interface | USB Micro 5 pin |
| Headphone jack | 3.5 mm |
| Language | English, Spanish, Portuguese (Brazil), Portuguese (podcast), Italian, German, Dutch, French, Polish, Romanian, Turkish, the Russian, Arabic, Indonesian, Malay,Thai, Vietnamese, Hindi, Hebrew, Simplified Chinese |
| Color | Yellow sun, army green, metallic grey |
| Shock resistant | 1-19 Hz / 1-1.0 mm 19-200 Hz / 1.0 g Acceleration amplitude |
| Shock resistance | Meet MIL - STD - 810 - g/Method516.6 / Procedure military protection grade IV |
| Waterproof grade | 6 class |
| Dust proof grade | 6 class |
| Reliability | MTBF > 50000 h; MTTR < 0.5 h |
| Working temperature | - 20 ° C to + 65 ° C |
| Storage temperature | - 40 ° C to +80 ° C |
| Relative humidity | 5% to 95% |
| Working height | Maximum working height:4500 meters |
