Features:

1.     the Lifting platform extension, according to the different models of the vehicle Support the ramp and extension, flexible use, cover small space.

2.     Pneumatic Release, safe and reliable.

3.     the Initial height is lower (110mm), have sliding ramp and extension.

4.     Adopt Axis driven, synchronization performance good, lifting capacity well.

5.     Hydraulic System adopted imported electromagnetic valve and seal components, ensure the Stability and working life of the machine.

6.     When the power supply is off, lift and vehicle can be down by manual.

7.     Rising and falling have safety alarm device.

8.     Oil Cylinder with upper return oil, prevent oil cylinder rust.

Technical Specifications:



Lifting Capacity	3000kg
Lifting Height	1000mm
Min.Height	110mm
Lifting Time	50s
Length of the platform	1400mm
Platform Width	530mm
Motor Power	3.0kw-380v/3.0kw-220v
Oil Pressure rating	24Mpa
Air Pressure	0.6-0.8 MPa
Weight	580kg
