Product Main

Quick Details

After-sales Service Provided: No overseas service provided
Condition: New
Brand Name: siedon
Weight: 1200
color: red

Specifications

the following example is for you reference.


1.Brief Introduction:

  SIEDON four shaft shredder has intelligent control system for each of shaft which enables every shaft working with their own shredding and protection actions to increase the shredding frequency and output. In addition, our shredder equipped hydraulic and electric motor combine driven system, which both remained the benefits of hydraulic and electrical driven, high torque and flexible for main shaft, efficient and power saving for vice shafts. Our four shaft Crusher can shred household appliance, hard plastic, bulky waste, tire waste, oil filter, hazardous waste, etc



2.Techincal parameters:



Model QS1012 QSH1316 QSH1618
Motor Power (kW) 2*45+2*30 160(hydraulic)+2*30 200(hydraulic)+2*55
Knife Thickness/Mesh Size (mm) 30/60/100 30/60/100 40/80/120
Size of Cutting Chamber (mm) 1020*1200 1300*1620 1800*1600
Machine Dimensions (mm) 4600*2880*2640 4800*2000*3500 3410*3260*3600



3.Performance features:

  • Every shredding shaft independent working, more efficient
  • Chamber structure optimized to reduce vibration and stress
  • Bearing pedestal and gearbox Integrated assembly
  • Modular design for quick maintenance
  • Alloy Shafts are strictly heat-treated for excellent toughness
  • Hexagonal surfaces of shaft are hardened to bear impact
  • Direct welding repair technologies for fast cutter maintenance
  • Central lubrication system with PLC automatic control

China Waste Crusher Four Shaft Shredder
