Chipset

AIT Chipset

Image sensor

4M CMOS sensor

 lens

H/125 degree,V/170 degree

Screen

Video


Stamps overlaying

Infrared mode

2.0 inch LCD screen

1920*1080/30fps,1280 *720(30-60fps), 960*544/(30fps). H.264 encode,   MP4 format

4M/8M/12M/16M,8X digital zoom,JPG

Including time,department,user ID

4pcs IR Infrared LED lamps, Manual or Auto, shooting distance ≥15m

Voice recording

High-sensitivity mic, support separate recording,  AAC

WiFi

Yes (Optional)

GPS (External)

Yes (Optional)

Playback

Video and textfiles playback in native machine, PC, TV and camera

Log recording

Time recording of operation, read on computer

2.4G Wireless remote

Light

Interphone connection

Yes (Optional)

High bright LED for auxiliary lighting

All kinds of interphones, monophone

AV in

Yes

AV OUT

No

HDMI

No

USB andEncryption

USB2.0 interface,AV-OUT, intercom password needed when usb connecting. Two levels of passwords. User password: can only view the data file, can't delete, modify. Administrator password: to view, exporting data, edit and delete data

Extension Interface

Can support external 3G transmitter

Storage

Built-in 32GB TF Card,64GB TF card can be optional,1GB recording time 11min/1080P,24min/720P,60min/D1 (the card cannot take out from the unit)

System settings

Menu&App,Set various parameters,such as the time correction,screen off time,save electricity pattern,resolution,bit rate,frame rate,video segmentation time and so on

Battery

3500 mA polymer lithium battery, 5 v / 1 A direct charger,charging time 5H

Pre/Post recording

Support

Continuous video recording time

1080P≥8H,720P≥10H,D1≥9H(LCD/IR off)

Standby time

≥25H

Professional back clip

Vertically 180 degrees,can be positioned

Free softwares

1.Win-Win HD camera setup APP
2.Web data collection and management system and Data Collection Station can be optional

Operating system

Windows XP/2003/vista/win7/win8

Working temperature

-2055

Storage temperature

-30°---70°

Working humidity

15%-95%

Dimensions

L*W*H  89x60x28mm

Weight

≤140g

Standard accessories

User manual,Car charger,DC charger,USB cable,back clip,32GB TF Card

Optional accessories

Car Suction Cup,Radio Cable,Dock station,External HD1080P/30fps IR camera,2.4G wireless remote controller,64GB TF Card,plastic case,WiFi function
