| Dimensions: | CARBIDE RODS DIA 0.5 to 50 mm |
|---|---|
| Brand Name: | Ruiao |
| material: | alloy |
| purity: | >98% |
| Certification: | ISO |
| Model Number: | Cabide rod |
| Place of Origin: | China (Mainland) |
| Standard: | DIN ANSI |
| Surface: | Sintered |
| Tolerance: | H4, H5, H6, H7 Standard |
| Run-out: | 0.05mm |
Quick Details
Specifications
the Tungsten Carbide
Rods, Blanks are made by Extrusion from the highest purity of Materials and
Sinter Hiped. Be of very high quality and tool peroformances, the grade
For Cutting tools are usually in Sub-micron Grain and Ultra-fine Grain. as
Demand,the other grade can be custom-made.
They are ideal materials for the Solid rotoary
Cutting tools, like Solid Carbide Endmill, Drills, Remaers, Taps.etc.
Usually, the carbide rods are in sintered conditions,
but we can arrange the grinding process as per the clients specific demand. Our
Grinding are done by the Imported Centerless
Grinding Machines, we can meet the precision demand of our
Cleints from both Europe and American, usually, we control them in h6
Finsihing, as demand, we can control it be h5, h4, h7.
We can even grind the Cemented carbide rods
Even in 0.3 mm diameter if you have.
the
Grades for the Carbide Rods:
the Grade of the Tungsten Carbide Rods | |||||
Properties of Grade |
RD10F |
RD10UF |
RD12UF |
RD06UF | |
Co |
% |
10 |
10 |
12 |
6 |
WC incl. Doping |
% |
90 |
90 |
88 |
94 |
Density |
g/cm3 |
14.45 |
14.45 |
14.1 |
14.9 |
Vickers Hardness HV30 |
Kg/mm2 |
1580 |
1790 |
1690 |
1890 |
Rockwell Hardness HRA |
ISO3738 |
91.8 |
92.5 |
>92.5 |
93.5 |
TRS |
N/mm2 |
3800 |
4000 |
4000 |
3900 |
Porosity |
A |
< 02 |
< 02 |
< 02 |
< 02 |
B |
0 |
0 |
0 |
0 | |
C |
0 |
0 |
0 |
0 | |
WC Grain Size |
μm |
0.8 |
0.5 |
0.4-0.5 |
0.5 |
** We have the Co 15%, medium Grain Carbide for Mold
Materials, like Punches, cores..
the Sizes
for the Carbide Rods:
Solid Carbide Rods (Full length) | |||||
Nominal Dia |
D(mm) |
D(mm) |
Length |
Remarks | |
D (mm) |
Un-ground |
h6 |
mm |
||
0.5 |
0.7 |
0.5 |
310-330 |
||
0.8 |
1 |
0.8 |
310-330 |
||
1 |
1.2 |
1 |
310-330 |
||
1.5 |
1.7 |
1.5 |
310-330 |
||
1/16" |
1.5875 |
1.8 |
1.5875 |
12" -13" |
Inchin size |
2 |
2.2 |
2 |
310-330 |
||
2.35 |
2.55 |
2.35 |
310-330 |
||
3/32" |
2.38 |
2.6 |
2.38 |
12" -13" |
Inchin size |
2.5 |
2.7 |
2.5 |
310-330 |
||
3 |
3.2 |
3 |
310-330 |
||
1/8" |
3.175 |
3.4 |
3.175 |
12" -13" |
Inchin size |
3.5 |
3.7 |
3.5 |
310-330 |
||
5/32 |
3.968 |
4.2 |
3.968 |
12" -13" |
Inchin size |
4 |
4.2 |
4 |
310-330 |
||
4.5 |
4.5 |
310-330 |
|||
3/16" |
4.7625 |
5.0 |
4.762 |
12" -13" |
Inchin size |
5 |
5.2 |
5 |
310-330 |
||
5.5 |
5.7 |
5.5 |
310-330 |
||
6 |
6.2 |
6 |
310-330 |
||
1/4" |
6.35 |
6.6 |
6.35 |
12" -13" |
Inchin size |
6.5 |
6.7 |
6.5 |
310-330 |
||
7 |
7.2 |
7 |
310-330 |
||
7.5 |
7.7 |
7.5 |
310-330 |
||
5/16" |
7.937 |
8.2 |
7.937 |
12" -13" |
Inchin size |
8 |
8.2 |
8 |
310-330 |
||
8.5 |
8.7 |
8.5 |
310-330 |
||
9 |
9.2 |
9 |
310-330 |
||
9.5 |
9.7 |
9.5 |
310-330 |
||
3/8" |
9.525 |
9.7 |
9.525 |
12" -13" |
Inchin size |
10 |
10.2 |
10 |
310-330 |
||
10.5 |
10.7 |
10.5 |
310-330 |
||
11 |
11.2 |
11 |
310-330 |
||
7/16" |
11.11 |
11.3 |
11.11 |
12" -13" |
Inchin size |
11.5 |
11.7 |
11.5 |
310-330 |
||
12 |
12.2 |
12 |
310-330 |
||
12.5 |
12.7 |
12.5 |
310-330 |
||
1/2" |
12.7 |
12.9 |
12.7 |
12" -13" |
Inchin size |
13 |
13.2 |
13 |
310-330 |
||
13.5 |
13.7 |
13.5 |
310-330 |
||
14 |
14.2 |
14 |
310-330 |
||
9/16" |
14.288 |
14.5 |
14.288 |
12" -13" |
Inchin size |
14.5 |
14.7 |
14.5 |
310-330 |
||
15 |
15.2 |
15 |
310-330 |
||
15.5 |
15.7 |
15.5 |
310-330 |
||
5/8" |
15.875 |
16.1 |
15.875 |
12" -13" |
Inchin size |
16 |
16.2 |
16 |
310-330 |
||
16.5 |
16.7 |
16.5 |
310-330 |
||
17 |
17.2 |
17 |
310-330 |
||
17.5 |
17.7 |
17.5 |
310-330 |
||
18 |
18.2 |
18 |
310-330 |
||
18.5 |
18.7 |
18.5 |
310-330 |
||
19 |
19.2 |
19 |
310-330 |
||
3/4" |
19.05 |
19.3 |
19.05 |
12" -13" |
Inchin size |
19.5 |
19.7 |
19.5 |
310-330 |
||
20 |
20.2 |
20 |
310-330 |
||
20.5 |
20.7 |
20.5 |
310-330 |
||
21 |
21.2 |
21 |
310-330 |
||
21.5 |
21.7 |
21.5 |
310-330 |
||
22 |
22.2 |
22 |
310-330 |
||
22.5 |
22.7 |
22.5 |
310-330 |
||
23 |
23.2 |
23 |
310-330 |
||
23.5 |
23.7 |
23.5 |
310-330 |
||
24 |
24.2 |
24 |
310-330 |
||
24.5 |
24.7 |
24.5 |
310-330 |
||
25 |
25.2 |
25 |
310-330 |
||
1" |
25.4 |
25.7 |
25.4 |
12" -13" |
Inchin size |
26 |
26.3 |
26 |
310-330 |
||
27 |
27.2 |
27 |
310-330 |
||
28 |
28.2 |
28 |
310-331 |
||
29 |
29.2 |
29 |
310-333 |
||
30 |
30.2 |
30 |
310-334 |
||
31 |
31.2 |
31 |
310-335 |
||
1-1/4" |
31.75 |
32.0 |
31.75 |
12" -13" |
Inchin size |
32 |
32.2 |
32 |
310-336 |
||
33 |
33.2 |
33 |
310-337 |
||
34 |
34.2 |
34 |
310-338 |
||
35 |
35.2 |
35 |
310-339 |
||
36 |
36.2 |
36 |
310-340 |
||
37 |
37.2 |
37 |
310-341 |
||
38 |
38.2 |
38 |
310-342 |
||
1-1/2" |
38.1 |
38.4 |
38.1 |
12" -13" |
Inchin size |
39 |
39.2 |
39 |
310-343 |
||
40 |
40.2 |
40 |
310-344 |
||
42 |
42.2 |
42 |
310-344 |
||
**Carbide Rods with Special Diameter and length can be made as request
TOLERANCES for Diameter and Length (h6) |
TOLERANCES for Roundness and Straightness (h6 ) |
| ||||
Size, mm |
D, h6 |
L |
Size, mm |
Straightness |
Roundness |
|
≤3 |
+0,-0.006 |
+5/+1 |
≤4 |
0.15 max |
0.004 max |
|
5 to 6 |
+0, -.008 |
5 to 10 |
0.08 max |
| ||
8 to 10 |
+0, -.009 |
10 to 13 |
0.06 max |
| ||
12 to 18 |
+0, -.011 |
>13 |
0.05 max |
| ||
20 to 24 |
+0, -.013 |
| ||||
