| Brand Name: | Jinzhen Boiler |
|---|---|
| Style: | Horizontal |
| Pressure: | Low Pressure |
| Usage: | Industrial |
| Condition: | New |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE |
| Weight: | 10ton |
| Dimension(L*W*H): | 4600mm*2350mm*2500mm |
| Output: | Steam |
| Model Number: | WNS3-1.0 |
| Place of Origin: | China (Mainland) |
| Fuel: | Gas-fired |
| Structure: | Fire Tube |
| Type: | Natural Circulation |
| steam capacity: | 3ton/h,3000kgs/h,200hp |
| pressure: | 10bar,13bar, 16bar |
| temperature:: | 184C, 193C, 205C |
| feature: | free installation |
Quick Details
Specifications
3T/H Industrial Natural Gas Oil Fired Steam Boiler for Feed Pellet Line
WNS series is a classical shell type steam boiler, with classical design: firetube+ wetback+ 3pass. Its average thermal efficiency >95%, design working life span more than 15 years. Equipped with well-known auxiliary parts, such as BALTUR/RIELLO- Burner, DANFOSS- Pressure Controler, SIEMENS- PLC operation system, LEO- Multistage Pump, etc. to ensure the boiler's steady performance. The entire system warranty period: 2 Years.
Free-Installation
Before the shipment, complete boiler system is well skid-mounted on the basement, also we have done the pipe(valves) connection and wire connection. after receiving the boiler, no need installation/ assembly. Just join the boiler to water/ gas/ electricity. Comparing with other traditional boilers in the market, our boiler does save lots of cost/ energy/ time in installation. The additional, the entire boiler system is portable.
Boiler Advantage
1.High pressure water supply pump
2.Burner:Italy:Baltur, Riello,Opel
Germany:Weishaupt,Elco
Finland:Oilon
High combustion efficiency, and ignition process control and overvoltage flameout protection function.
3.Electric control cabinet:
Touch screen
Two language
PLC control system
the functions of automatic water supply, automatic ignition, overpressure and overtemperature,flameout, advanced remote control function, on-line monitoring of dosage and fault alarm.
4.Automatic water treatment
Reduce the content of Ca2+ Mg2+ in water,avoid scaling of boiler,prolong boiler service life.
5.Steam header
According to the customer demands, design the cylinder outlet size and quantity
Heavy oil /Light oil/Natural gas/Liquefied petroleum gas ( LPG )/Coke Oven Gas(COG)
Scope of application:
1. Industrial user: pharmaceutical, paper, tobacco, printing and dyeing, garment and other industries;
2. Civil: catering, laundry, ( hospital ) disinfection, sauna, etc;
3. by steam - water heat exchanger for heating systems ( air conditioning, radiators, floor heating, etc. ) of hot water;
4. Provide power for the lithium bromide absorption chiller (pressure P = 0.6-0.8Mpa)
