Fabric shrinkage tester Y(B)089E
[scope of application] used for dimensional stability testing of fabrics, garments or other textiles after washing.
[related standards]
GB/T8629 (national standard drafting unit)
GB/T8630 ISO6330/5077 FZ/T70009 BS4923 EN25077/26330 JIS L1909, IWSTM31 IEC456 M&S and so on.
[instrument characteristics]
1, imported VVVF variable speed motor, high speed dehydration coefficient, digital setting;
2. Domestically initiated fully independent suspension drum technology with high shock-proof performance, super-quiet operation, no need for foot fixation
3. the inside and outside of the machine and the industrial handle are made of high-grade stainless steel. the industrial structure is designed, beautiful and delicate, durable.
4, 7 inch LCD touch screen menu operation in Chinese and English;
5, 32 industrial level imported single-chip microcomputer intelligent control, ensure long run smoothly;
6. High precision contact pole type water level controller to ensure accurate and reliable water level.
[technical parameters]
1,Category:A type washer front door feeding and horizontal drum type.
2,Rated loading capacity:5kg
3. Inner cylinder diameter:(520±1)mm
4, inner cylinder depth:(315±1)mm
5, lifting film
Number:3 slices
Height:(53±1)mm
Length:Extend to inner drum entire depth.
Spacing:1200
6. Outer cylinder diameter:(554±1)mm
7. Rotation:
Normal rotation time interval:(12±0.1)s
Normal stopping interval:(3±0.1)s
Detente rotation time interval:(8±0.1)s
Relaxation interval:(7±0.1)s
Soft turning time interval:(3±0.1)s
Soft stopping interval:(12±0.1)s
8, speed:Digital setting, stepless speed regulation up to 40-800rpm
in the procedure:Washing (52 + 1) rpm
Low speed dehydration (500 + 20) rpm
High speed dehydration (800 + 20) rpm
9. Water supply system:
Water supply flow (20 + 2) L/min (inlet pressure should be higher than 150KP condition).
Water level detection 2 files 100mm and 150mm (tolerance difference less than 3mm)
Drainage speed > 30L/min
10. Temperature detection:Temperature sensor, digital setting range:Room temperature --99 degrees C + + 1 C, resolution 0.1 C
11. Washing procedures:23 sets of automatic washing procedures.Another set of self archiving scrubbing processes.Manual single control flow
12, heating power:5.4±2%KW
13. Size:(7506501190)mm(LWH)
14, weight:130Kg
15, power supply:AC220V 50Hz 6.5KW
