the following example is for you reference.


1.Brief Introduction:

24-hour printing production

Daily output: 10000-13440square meters

High precision industrial print head

Exquisite sharpness gives perfect clarity

Variable drop size

World's top brand components

Higher ink concentration more economical

Intelligent output and ink consumption management





2.Techincal parameters:

XC08 Technical Specifications
Model		XC08-48
Max.Printing Width		4200mm
Printing Mode		6 colours with 48 print heads
Printing Speed	Mode 1	560sqm/h
	Mode 2	300sqm/h
	Mode 3	200sqm/h
Print Head	Model	Industrial starfire print head
	Quantity	48 pieces
	Height	Adjustable up to 50mm above the fabric
	Cleaning Method	Auto positive and negative pressure cleaning system
	Wetting Control Method	by pneumatic spray nozzle
Ink	Type	Reactive,disperse,acid,reducing and pigment ink
	Colors	C, M, Y, K, Orange, Blue, Red,Grey,LC,LM
Fabric		most of the fabric are availabe
Take up and Drying		Automatic take-up system, infrared dryer





3.Performance features:

Work Station		Windows 10 64bit
		CPU:Inter Core i7 6700K
		HD: 1T
		RAM:32GB
RIP Software		Wasatch/neostampa
Image Format		JPEG, TIFF, BMP/RGB, CMYK
Power	Supply	380VAC
	Frequency	50HZ+10%
	Consumption	around 25KW
Working Conditions		Room temperature 20C-30C,Humidity 55%-70%
Equipment Dimensions (Including dryer)		3370mm (L)
		7100mm (W)
		2000mm (H)
