| Brand Name: | JPLS |
|---|---|
| Temperature of Media: | Medium Temperature |
| Material: | Ductile iron |
| Pressure: | Medium Pressure |
| Standard or Nonstandard: | Standard |
| Model Number: | UD341XP-10K(Q) |
| Place of Origin: | China (Mainland) |
| Port Size: | DN50-DN300 |
| Media: | Water |
| Power: | Manual |
| Structure: | Butterfly |
| MATERIAL: | DUCTILE IRON |
| DRIVE: | WORM GEAR |
| USAGE: | MARINE |
| PRESSURE: | PN10/PN6 |
| STANDARD: | JIS |
| COLOR: | BLACK,GREEN,WHITE OR CUSTOMER REQUIREMENTS |
| PACKAGE: | PLYWOOD CASE |
Quick Details
Specifications
Size: DN40 - DN1200
Pressure: PN1.0-1.6MPa
Design: ISO 5752 / BS 5155 / API 609
Body: Cast iron, Ductile Iron
Seat: EPDM, NBR
Stem: Stainless Steel, Steel
Disc: Ductile Iron with Nickel Coating,Ductile Iron with Nylon Coating, Stainless Steel 304/316, Al-Bronze
Flange Connection: DIN, BS, ISO, ANSI, as, JIS
Product Features
U type flanged body style fit between FF or RF flanges
Suitable Medium: water, sewage, sea water, air, foodstuff, oil
Working temperature: -10C - 150C
Suitable for gear operators, electric and pneumatic control actuators.
