Tumble blast machine with rubber belt is ideal for mass-produced parts, which can be tumbled and will perfectly meet your requirements for batch cleaning, decoring, descaling, deflashing, deburring, and shot peening parts. They are mostly used for process ferrous and non-ferrous castings, forgings and heat treated parts.
the use of a rubber belt conveyor ensures a relatively gentle tumbling motion. Because clearances are kept small, it is also possible to blast extremely tiny work pieces.
Shot blasting machine type Q32 series can be integrated to a fully automatic process with addition of loading and unloading equipment. Tumble blast machines are built in size that can accept single fill / load from 200kg up to 1,350 kg.



 Machine Features:

• Automatic door optional;
• Cabinet liner options utilizing cast manganese alloy materials;
• Touch screen operator interface and integrated PLC optional;
• High efficiency bag type dust collectors;
• Two steps air wash separator;
• Semi-automatic or fully automatic loader optional;
• Direct drive, spindle drive or variable speed abrasive wheels;
• Commercially available parts and components;
• Cast manganese steel belt available on steel belt versions;
• Modular design allows for simple assembly of the equipment on site.

Technical parameters





Item	Unit	Q326C	QR3210	QR3220	15GN	28GN
Productivity	T/h	0.6-1.2	1.5-2.5	4-5	5-6	10-12
Max. Feeding amount	Kg	200	600	1200	1300	3500
Max. Single workpiece weight	Kg	10	30	40	230	363
End disk diameter	mm	?650	?1000	?1000	?1092	?1245
Effective volume	m3	0.15	0.3	0.4	0.43	0.79
Blasting capacity	Kg/min	100	250	500	480	700
Ventilation volume	m3/h	2200	5000	10000	5300	6500
Power consumption	Kw	12.6	24.3	51	49.3	64.5
