| Brand Name: | NGI |
|---|---|
| color: | White |
| Theory: | Power consumption |
| Resolution: | High resolution |
| Size: | 19 inch 3U/6U |
| Model Number: | N62400 |
| Place of Origin: | China (Mainland) |
| Interface: | RS232/LAN/CAN |
| Output Channels: | 1 channel |
| Power Specification: | 1kW/2kW/3kW/4kW/5kW/6kW |
Quick Details
Specifications
N62400 Series Low Voltage High Current DC Electronic Load
Product Introduction
N62400 series is developed based on NGI's years of experience in testing for fuel cell. It is with high accuracy, high reliability and high cost performance. N62400 series is with high power density and elegant appearance, which is available for benchtop use or installation in 19 inch rack.
Application Fields
1. Fuel cell test
2. Other low voltage & high current applications
Main Features
*Min. Operating voltage as low as 0.2V for full current 1200A
*Stable and reliable CR/CP function supported by hardware
*Powerful charging & discharging control function, convenient for fuel cell test
*Built-in ESR test function (Optional)
*Dynamic mode up to 20kHz, editable rise and fall slew rate
*Remote/local sense
*Power-off memory function
*Programmable sequence testing function(SEQ), up to 100 groups sequence files, up to 50 steps per file
*LCD screen for data display
*Built-in auto test function, one-button operation for complex test tasks
*Analog programming interface(APG), current monitoring interface, remote/local trigger function to realize
Complex function control and monitoring
*Standard 19-inch, available for rack installation
*Short-circuit simulation
Product Introduction
N62400 series is developed based on NGI's years of experience in testing for fuel cell. It is with high accuracy, high reliability and high cost performance. N62400 series is with high power density and elegant appearance, which is available for benchtop use or installation in 19 inch rack.
Application Fields
1. Fuel cell test
2. Other low voltage & high current applications
Main Features
*Min. Operating voltage as low as 0.2V for full current 1200A
*Stable and reliable CR/CP function supported by hardware
*Powerful charging & discharging control function, convenient for fuel cell test
*Built-in ESR test function (Optional)
*Dynamic mode up to 20kHz, editable rise and fall slew rate
*Remote/local sense
*Power-off memory function
*Programmable sequence testing function(SEQ), up to 100 groups sequence files, up to 50 steps per file
*LCD screen for data display
*Built-in auto test function, one-button operation for complex test tasks
*Analog programming interface(APG), current monitoring interface, remote/local trigger function to realize
Complex function control and monitoring
*Standard 19-inch, available for rack installation
*Short-circuit simulation
