| Size: | 40*3*3 |
|---|---|
| Type: | Abrasive Disc |
| Brand Name: | Moresuperhard |
| Material: | diamond |
| Grit: | 200 |
| Model Number: | 40*3*3 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Cylinder Diamond & Cbn Honing Stone
Diamond & CBN honing stone, honing stick
Bonded: metal bond
Materials of workpiece: carbide,glass and ceramic,cast iron,alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve,oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.
Cylinder
More Superhard provide superabrasive diamond and CBN honing stone for honing machines of almost all renowned honing brands (Sunnen, Nagel, Belden, AccuCut, Engis, and other types of high-production honing equipment ). Our diamond and CBN honing stones are available for precisiom bore finishing.
Applications of Diamond and CBN Honing Stone
Materials of workpiece: carbide, glass and ceramic, cast iron, alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve,oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.
Applicable honing machine: Sunnen, Nagel, Belden, AccuCut, Engis, and other types of high-production honing equipment
Specifications of cylinder honing stone
| Model | Size | Grit | ||
| Diamond and CBN honing stone | L (mm) | Width (mm) | Height (mm) | 120#150# 150#240# 240#~W40 W40~W20 W20 |
| 16-35 | 2, 3, 4, 6 | 2, 3, 4 | ||
| 40, 50 | 2, 3, 3.5, 4 | 1, 1.5, 2, 2.5, 3, 3.5, 4 | ||
| 60, 70 | 1.5, 2, 3, 3.5, 6, 8 | 2, 2.5, 3, 3.5, 4, 6.5, 7, 8 | ||
| 80, 90 | 3, 4, 5, 6, 8, 9, 9.5 | 3, 4, 5, 6, 7, 8, 10 | ||
| 100, 120 | 2, 3, 5, 6, 8, 9, 12, 15 | 3, 4, 5, 6, 7, 8, 10, 12, 15 | ||
| 140, 150 | 3, 5, 6, 8, 9, 12 | 4, 5, 6, 7, 8, 10, 12 | ||
| 200 | 8, 10, 15, 20, 40 | 8, 10, 15, 20 | ||
| Other specifications honing stone can be made according to customers' requirement. | ||||
