1, Performance characteristics:
1. Overall welding, stable structure
2. European original imported hydraulic system, superior performance
3. Gear transmission, accuracy up to 0.1 mm
4. High precision Y-axis depth digital display, can be adjusted manually
5. Standard die clamping block, up and down die in accordance with European and Japanese standards
6. Various numerical control systems can be selected
2, Advantages of equipment components
1. Weighted solid synchronous shaft ensures left and right synchronization and smooth operation of slide block
2. Specially designed heavy back finger with first wheel up and down adjustment
3. Back stop material standard Taiwan ball screw, ordinary motor, variable frequency drive, can be installed with linear motor
Guide roller and servo motor
4. Worm gear reducer is used to adjust the depth of oil cylinder to ensure the accuracy of bending angle
5. X-axis electric back stop, electric button to adjust forward / backward, and SIKO mechanical digital display,
Fine adjustment of hand wheel
3, Optional control system
1. Estron E21 (China)
Control of rear stop and block
Control common motor or inverter
Intelligent positioning
Workpiece count
Pressure maintaining and unloading time setting
Chinese / English
40 program storage, 25 steps for each program
2. Maper ht072 (Italy)
Control speed of frequency converter
Control Y-axis and X-axis position, easy to use
It can keep multiple bending records for future operation at any time
Save time and effort, accurate bending
Including 99 programs, each program has 20 steps
Work piece calculation, working time display
Concession function
Metric / English
3. Delem da-41 (Netherlands)
High Definition LCD display
Slider stop position control
Back stop control
Angle becomes
Mold parameter setting
Escape control function
100 programs
Each program has 25 steps
Panel mounting
