| Product Name: |
Lifepo4 Battery 12v 200ah lithium ion solar battery pack BMS built in bluetooth |
| Model |
KH-LFP12200 |
| Nominal Capacity |
200Ah |
| Minimum Capacity |
198Ah |
| Nominal Voltage |
12V |
| Max.Charging voltage |
14.6V |
| Discharging cut-off voltage |
10V |
| Max. Continuous charge current |
100A |
| Max continuous discharging current |
250A |
| Max.Pulse current |
300A(<3S) |
| BMS with Bluetooth |
Inbuilt |
| Operation charge temperature |
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Operation discharge temperature |
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
| Warranty |
3 year |
| Cycle Life (DOD) |
4000 cycles@ 80%DOD |
| Protection |
over discharge,over charge,Short-circuit,over heating,Crush,Impact,Low-pressure,Seawater soak |
| Certification |
CE,ISO,UL,CB,BIS,ROHS,MSDS,UN38.3,IEC,TUV |
| Dimensions (L*W*H) |
520*240*222mm |
| Weight |
20KG |
