| Type: | Coaxial |
|---|---|
| Brand Name: | ALLEN |
| Application: | DUCT,AERIAL |
| Color: | BLACK |
| Model Number: | GJYXFCH |
| Place of Origin: | China (Mainland) |
| Strength member: | FRP |
| Armored: | Steel wire |
| Fiber Type: | G652D,G657A1,G657A2 |
| Jacket Material: | LZSH |
Quick Details
Specifications
GJYXCH Feature
1: Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
2: Two STEEL WIRE strength members ensure good performance of crush
3: Singel steel wire additional strength member ensure tensile strength
4: Easily strip and splice,simplify installation
5: Low smoke,zero halogen and flame sheath
Applications:
- Used in access network or as access cable from outdoor to indoor in customer premises.
- Used as access building cable in premises distribution system, eSpecially used in indoor or outdoor aerial access cabling.
Options:
Fiber Type: G.652D, G.657A1 or G.657A2 single mode fiber
GJYXCH Features
Optical Characteristics
| Fiber Type | Attenuation | Overfilled launch Bandwidth | Effective Modal Bandwidth | 10GB/S Ethernet link length | Min Bending Radius | |
| Conditions | 1310/1550nm | 850/1300nm | 850/1300nm | 850nm | 850nm | |
| Unit | dB/km | dB/km | MHZ.Km | MHZ.Km | m | mm |
| G652D | 0.36/0.22 | 16 | ||||
| G657A1 | 0.36/0.22 | 10 | ||||
| G657A2 | 0.36/0.22 | 7.5 | ||||
| 50/125 | 3.0/1.0 | ≥500/500 | 30 | |||
| 62.2/125 | 3.0/1.0 | ≥200/500 | 30 | |||
| OM3 | 3.0/1.0 | ≥1500/500 | ≥2000 | ≥300 | 30 | |
| OM4 | 3.0/1.0 | ≥3500/500 | ≥4700 | ≥550 | 30 | |
| B1-OM3 | 3.0/1.0 | ≥1500/500 | ≥2000 | ≥300 | 7.5 | |
| B1-OM4 | 3.0/1.0 | ≥3500/500 | ≥4700 | ≥550 | 7.5 | |
Structure and Technical Specification
| Fiber Count | Cable Diameter (mm) |
Cable Weight (kg/km) |
(N/100mm) |
Crush Resistance (N/100mm) | |||
| Short Term | Long Term | Short Term | Long Term | ||||
| 6-12 | 3.0*9.0 | 27 | 1200 | 600 | 1000 | 500 | |
