| Nominal Capacity: | 1200mAh |
|---|---|
| Size: | Prismatic |
| Battery Type: | LiMnO2 |
| Brand Name: | GN |
| Shelf life: | 10 years |
| Model Number: | CP502440 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Part No.: CP502440
Nominal Voltage: 3.0V
Nominal Capacity: 1200mAh
Max Discharge: 300mA continuous
Pulse Capacity: up to 500mA (Varies according to pulse characteristics, temperature, cell history and the application. Consult GN)
Typical Weight: 9.0 grams
Storage Temp: -5℃ to 35℃
Exterior/Housing: Laminated Lluminum Foil
Wide Operating Temperature Range
-20°C to +60°C
Special models with operating temperature -40°C to + 80°C available
Long Shelf Life
Self discharge rate is less than 2% per year at room temperature
No passivation effect, instant install-and-use, maintenance free
Ultra thin
Variable Design
Battery of variable dimensions can be selected to fit in the customer's design
Customize batteries and packs are available
Greater Safety
the structure of the battery offers greater safety to meet customer's requirement for special applications
