| Type: | Flexographic Printer |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Color & Page: | Two Colors |
| Usage: | Cloths Printer,Label Printer,Paper Printer, |
| Brand Name: | Qianrun |
| Condition: | New |
| Certification: | CE |
| Weight: | 10,000KG |
| Dimensions(L*W*H): | 10830X1560X1520mm |
| Voltage: | 380V |
| Automatic Grade: | Automatic |
| Model Number: | Q5-370 |
| Place of Origin: | China (Mainland) |
| Plate Type: | Letterpress |
| max printing speed: | 200m/min |
| printing color: | 10c |
| max web width: | 412mm |
| max prinitng width: | 370mm |
| max unwinding diameter: | 1000mm |
| max rewinding diameter: | 1000mm |
| printing length: | 139.7mm-609.6mm |
Quick Details
Specifications
GUANGDONG QIANRUN MACHINERY SCI&TECH CO., LTD
Dasha Square, Dalingshan Town, Guangdong Province, China
1. Features
1.1 Our machine adopts famous petal structure Filling plate, anilox roller and plate roller can be changed in seconds without any tools.
1.2 Combining stufenloser Antrieb, automatic pre - registration and overprinting helps client save time and save material.
1.2 Combining stufenloser Antrieb, automatic pre - registration and overprinting helps client save time and save material.
1.3 High precision unique clutch pressing mode, plate roller, anilox roller pressing position in one place, no adjustment.
1.4 6m flow flat configuration for varnish for your choose.
1.5 LED UV drying system (can increase mercury lamp interchange), energy saving and environmental protection, flexible adjustment according to different ink characteristics.
1.4 6m flow flat configuration for varnish for your choose.
1.5 LED UV drying system (can increase mercury lamp interchange), energy saving and environmental protection, flexible adjustment according to different ink characteristics.
1.6 Optional vision registration system, each prinitng unit can observe the printing quality and registration effect in real time. so no need to pass web, deviation can be adjusted automatically or manual by display. this design can help us save materials.
1.7 Fast disassembly of rotary semi-circular arc die-cutting slider design, the replacement of die-cutting roller or magnetic roller fast and convenient, reduce human factors caused by mechanical precision wear and reduction.
2. Standard configuration
Registration retain system, Elevation type air shaft, Snowball type waste rewinder, Cold stamping unit, Turn bar, Independent touch panel.
Registration retain system, Elevation type air shaft, Snowball type waste rewinder, Cold stamping unit, Turn bar, Independent touch panel.
3. Optional configuration
Two die-cut units, Shear unit, Corona, Third die-cut unit, Sheet cut unit, Web cleaner, Positioning cold wave unit and Rotary screen printing device.
4. Technical Parameter
Model |
Q5-370-8C |
Q5-420-10C |
Max Printing speed |
200m/min |
200m/min |
Printing color |
8C |
10C |
Max. Web width |
412mm |
462 |
Max .Printing width |
370mm |
420 |
Max. unwinding diameter |
Φ1000 mm |
Φ1000 mm |
Max. rewinding diameter |
Φ1000 mm |
Φ1000 mm |
Printing length |
139.7mm-609.6mm |
139.7mm-609.6mm |
