LTE

 3GPP Release 12, Cat 12

 Max DL/UL Rate:

  LTE-FDD: 600Mbps/150Mbps

  LTE-TDD: 450Mbps/90Mbps

 Antenna: Internal and Omni-Directional

 up to 5 APNs

 Multi Bands Combination:

 DL up to 3CA, 256QAM; UL 2CA, 64QAM

 DL 4x4 MIMO

 Band Width

  FDD: 5MHz, 10MHz, 15MHz, 20MHz

  TDD: 10MHz, 15MHz, 20MHz

 Transmission Mode

  FDD: TM2, TM3, TM4

  TDD: TM2, TM3, TM4, TM7, TM8, TM9

 Frequency Bands

  LTE FDD: Band 1/3/7/20/28

  LTE TDD: Band 38/40/41/42/43

  DL 2x2 MIMO: Band 20/28

  DL 4x4 MIMO: Band 1/3/7/38/40/41/42/43

 Antenna

  Antenna Gain:700 MHz - 960 MHz: 1 - 2dBi

                           1710 MHz - 2690 MHz: 6 - 7dBi

                           3400 MHz - 3800 MHz: 8 - 9dBi

  Impedance:50Ω

 CA Combinations

  DL 2CA:

  1+1, 1+3, 1+7, 1+20, 1+28, 3+1,

  3+3, 3+7, 3+20, 3+28, 7+1, 7+3,

  7+7, 7+20, 7+28, 20+1, 20+3, 20+7,

  28+3, 28+7, 38+38, 40+40, 40+42,

  41+41, 41+42, 42+40, 42+42, 43+43

  DL 3CA:

  1+3+7, 1+3+20, 1+7+20, 3+1+7, 3+1+20,

  3+3+1, 3+3+8, 3+3+20, 3+7+20, 7+1+3,

  7+1+20, 7+3+20, 20+1+3, 20+1+7, 20+3+7,

  28+3+3, 40+40+40, 40+42+42, 41+41+41,

  41+41+42, 42+42+42

  UL 2CA:

  3+3, 7+7, 38+38, 40+40, 41+41, 42+42

 Receiver Sensitivity

  Band 1:100 dBm@5 MHz, 97 dBm@10 MHz,

               95.2 dBm@15 MHz, 94 dBm@20 MHz

  Band 3:97 dBm@5 MHz, 94 dBm@10 MHz,

               92.2 dBm@15 MHz, and 91 dBm@20 MHz

  Band 7:98 dBm@5 MHz, 95 dBm@10 MHz,

               93.2 dBm@15 MHz, 92 dBm@20 MHz

  Band 20:97 dBm@5 MHz, 94 dBm@10 MHz,

                 91.2 dBm@15 MHz, and 90 dBm@20 MHz

  Band 28:98.5 dBm@5 MHz, 95.5 dBm@10 MHz,

                 93.7 dBm@15 MHz, and 91 dBm@20 MHz

  Band 38:97 dBm@10 MHz, 95.2 dBm@15 MHz, and 94 dBm@20 MHz

  Band 40:97 dBm@10 MHz, 95.2 dBm@15 MHz, and 94 dBm@20 MHz

  Band 41:95 dBm@10MHz, -93.2 dBm@15MHz,-92 dBm@20 MHz

  Band 42:96 dBm@10MHz, -94.2 dBm@15MHz,-93 dBm@20 MHz

  Band 43:96 dBm@10MHz, -94.2 dBm@15MHz,-93 dBm@20 MHz

Interface

 1 x GE PoE LAN

 1 x SIM Card Slot(3FF, micro-SIM card)

 1 x LED Indicator for Power, System and LTE

Signal Strength

 1 x Reset Button

 Built-in Omni-Directional LTE Antennas



Certification

 CE, RoHS, REACH, WEEE

Router Functions

 DHCP Server

 NAT, DMZ

 VPN Passthrough

 IPv4, IPv6, IPv4/v6

 Static Route, Policy Route

 IP Passthrough

 Firewall

  URL/Domain Filtering

  MAC/IP/Port Filtering

 System log

 Management:

  Web, SNMP, TR069



Environmental

 Size: Φ125 mm x 240 mm

 Net Weight: 1450g

 Power Supply: Non-Standard PoE

 Ingress Protection: IP65

 ESD Protection:

  Contact±8KV, Air±10KV

 Operation Range:

 -40℃ to 55℃

 Humidity:

 10%-95%, non-condensing

 Installation:

 Pole-Mounted, Wall-Mount
