| Brand Name: | Huifan Security |
|---|---|
| Face Capacity: | 2000 |
| Fingerprint Capacity: | 0 |
| Display: | 8 inches touch screen, full view angle, IPS LCD screen |
| Communication: | RS232/4G,EU COVID Certificate Green Pass, HDMI, PDF417, QR Code, Healt |
| Model Number: | RA08TP |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| Screen | |
Dimension |
8 inches touch screen, full view angle, IPS LCD screen |
Resolution |
1280800 |
| Thermal Sensor | Heiman Sensor HTPA80*64d |
| Camera | |
Dual Camera |
2.0M (RGB Camera); 1.0M (Infrared Camera) |
Type |
Wide dynamic camera |
Aperture |
4mm |
Focal Length |
0-2m |
White Balance |
Automatic |
Wide Dynamic |
Support |
Vertical Wide Angle |
|
Horizontal Angle |
|
| Core Parameter | |
| CPU | 4 cores, 1.8GHz |
Memory |
2GB RAM, 8GB ROM |
| OS | Android 7 |
| Accessories | |
| Filling Light | LED filling light |
| Card Reader (Optional) | IQR Code, RFID, HID, Thermal printer, 4G, HDMI, Micro phone, GPS, etc |
| Network Module | Support wired, wireless (2.4G Wi-Fi),optional 4G |
| Interface | |
Audio |
1 channel audio output (line out) |
| Serial Communication Interface | RS232 |
Interface |
USB 2.0, RJ45, Externale QR Code |
| Relay Output | Support |
| Wiegand Interface | Support Wiegand 26/34 input /output |
| Reset Interface | Yes |
| Function | |
| Face Detection | Support detecting and tracking 5 people at the same time |
| 1:N Face Recognition | 99.99% |
| Face Capacity | 20,000 |
| 1:1 Person Certificate Comparison | More than 99% |
| Temperature detection | Support |
| Stranger Detection | Support |
| Remote Upgrade of Equipment | Support |
| Recognize Distance | Support |
| Protection Level | IP64, certain dustproof and waterproof function |
| Palm | |
| Grayscale | 256 levels |
| Image Size | 480* 640 |
| Distortion Rate | <1% |
| Connector | 7-pin 1.25mm USB2.0 |
| Power Consumption | 0.5W(Standby )/1.5 W (operating) |
| Interface | USB2.0(High speed) |
| Power Requirements | USB 5V |
| Temperature | -10°℃~45℃ / 14°F~113F |
| Humidity | 0 ~90%RH |
| Lighting Environment | Enrollment <80OLux;Authentication <200OLux |
| Dimensions | 52.4*52.4*16.8mm (±1 mm) |
| Window | Window |
| Android | Android 4.1 or higher |
| Recognition Angle | Roll ±60°, Pitch ±30° |
| Recognition Method | 1:1,1:N |
| Capacity | 6,000 templates |
| Accuracy | FRR=0.68% when FAR=0.001% |
| Recognition Time | <300ms (quad core Cortex A9 up to 1.6GHz) |
| General Parameters | |
| Power Supply | DC12V (±10%) |
| Operating Temperature | 16℃~30℃ |
| Working Humidity | 10% to 90% |
| Power Consumption | 10W MAX |
| Installation Method | Turnstile, Wall mounted, Desktop, Floor Type |
| Device Size | 234(L)*125(W)*24.5(H)mm |
| Weight | 3KG (Device Only) |
