Screen

Size

8 inch, IPS LCD screen

Brightness

500 LU

Resolution

800*1280 HD screen

Camera

Resolution

200W*200W

Number of cameras

 2

Type

RGB camera

Aperture

F2.0

Focal length

4.3mm

White balance

Auto

Wide dynamic

Support

Core parameter

CPU

Quad core, 1.8GHz

Device interface

Memory 2GB, storage 8GB

Audio

1 channel audio output(line out

Video

HDMI2.0 Type-A interface 1

Relay output

1 relay interface

Network Interface

1 RJ45 10M/100M adaptive Ethernet port, WiFi

Face Detection

Support detection and tracking of 5 people at the same time

1: N Face recognition

under the condition that the false recognition rate is three out of ten thousand, the recognition accuracy rate is 99.7%

Stranger detection

Support

Features

Recognition distance configuration

Support

Live detection

Support

UI interface configuration

Support

Remote upgrade of equipment

Support

Deployment method

Support public network and local area network use

Personal identification

Support(Purchase ID card reader separately)

Human body temperature detection

Support

Temperature detection distance

Within 1 meter

Temperature measurement accuracy

≤ ±0.3℃

Temperature range

30℃~42.5℃

the visitor's temperature is normal and let go

Support

Body temperature alarm value can be set

Support

Mask recognize

Support

High temperature alarm

Support

QR code recognition

Support optional

Second-generation ID Card Recognition

Support optional

Touch Screen function

Touch Screen Function

Partial model support

General Parameters

Protection level

IP42

Power supply

DC12V(±10%)

Operating temperature

-10℃60℃

Working humidity

10%90 %

Power consumption

10W MAX

Size

275*125*24(mm)

Weight

≈2kg
