| Chemical Composition: | niobium |
|---|---|
| Material: | niobium |
| Shape: | round |
| Application: | Aviation, Electronics, Industrial, Medical, Chemical |
| Brand Name: | ZZOK |
| Dimensions: | as shown |
| Model Number: | Niobium foil |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
[ Niobium foil] Introduction:All niobium and niobium alloys foil & strip products follow standard ASTM B393, such as pure niobium foil & strip (R04200, R04210), Nb1Zr (R04251 R04261), Nb10Zr , C-103, Cb-752, C129Y, FS-85, Nb-50Ti foil & strip and so on.
Niobium strip/foils are often deformed very well even far below room temperature. whether for punching, cutting, deep drawing or pressing: you'll be able to machine our Niobium strip/foils without difficulty to meet your specific needs. Niobium is significantly corrosion resistant. Acids and bases cannot damage our strip/foils. Strip/Foils fabricated from Niobium are used for instance within the chemical industry for water purification or as diffusion barrier in x-ray machines.
[ Niobium foil] Chemistry:
[ Niobium foil] Apprance:
Shape: foil/strip
Colour:Silver
Surface: Polished or According to Customer's Requirement
[ Niobium foil] Picture:
Niobium strip/foils are often deformed very well even far below room temperature. whether for punching, cutting, deep drawing or pressing: you'll be able to machine our Niobium strip/foils without difficulty to meet your specific needs. Niobium is significantly corrosion resistant. Acids and bases cannot damage our strip/foils. Strip/Foils fabricated from Niobium are used for instance within the chemical industry for water purification or as diffusion barrier in x-ray machines.
[ Niobium foil] Chemistry:
| Chemistry% | ||||||||||||
| Designation | Chief component | Impurities maximum | ||||||||||
| Nb | Fe | Si | Ni | W | Mo | Ti | Ta | O | C | H | N | |
| Nb1 | Remainder | 0.004 | 0.003 | 0.002 | 0.004 | 0.004 | 0.002 | 0.07 | 0.01 | 0.004 | 0.0012 | 0.002 |
| Nb2 | Remainder | 0.005 | 0.005 | 0.005 | 0.01 | 0.01 | 0.004 | 0.1 | 0.015 | 0.01 | 0.0015 | 0.01 |
Table 2. Mechanical requirements (annealed condition)
| Grade | Tensile strength δbpsi (MPa), ≥ | Yield strength δ0.2, psi (MPa),≥ | Elongation in 1/2 gage length, %, ≥ |
| RO4200-1 RO4210-2 |
18000 (125) | 10500 (73) | 25 |
| Special requirements to be agreed on by the supplier and buyer of negotiations | |||
[ Niobium foil] Apprance:
Shape: foil/strip
Colour:Silver
Surface: Polished or According to Customer's Requirement
[ Niobium foil]Application:
Pure niobium foil & strip is used to produce synthetic diamond. Niobium foil & strip is applied in illuminant material and electric light source. It can also be used as a thermal protection, structural material, vacuum tube and other electrical vacuum devices in aerospace industry.
[ Niobium foil]Advantage:
Excellent Corrosion Resistance
Good resistance to effect of heat
[ Niobium foil] Picture:
