Certification: | ISO CE |
---|---|
Plating: | paiting |
Material: | New |
Type: | Casting Parts |
Brand Name: | Bestech |
Place of Origin: | China (Mainland) |
Size: | cutomzied |
color: | customized |
Application: | foundry machinery |
Quick Details
Specifications
Main Technical Function:
Mode of operation: manipulating disc valve control
Parting mode: vertical parting
Mode of feeding sand: auto quantitive feeding sand
Temperature control: temperature automatically display, selecting high and low temperature be controlled by the instrument.
Mode of installing mould: two extremes movable mould, middle cover die, shoot two mould once.
Mode of heating mould: electric heating
Special specification can be made according to customer's need.
Design and product mould for the user.
Technical Parameter
We can design and produce by every client's required
Model |
Z9403 |
Z9404 |
Max Dimensions of mold board(mm) |
500*400 |
650*450 |
Max sand core weight(kg) |
20 |
20 |
Heating mode |
Electric heating |
Electric heating |
Assembly power(kw) |
Set according to the mould's size |
Set according to the mould's size |
