Gender: | Male |
---|---|
Application: | Audio & Video |
Type: | wafer |
Brand Name: | CNT |
Color: | Black |
Model Number: | CNT-W250-1XX-TS |
Place of Origin: | China (Mainland) |
Quick Details
Specifications
SPECIFICATIONS:
Current Rating:3.0 A
Insulation Resistance:1000MΩ Min
Dielectric Withstanding:1000V AC
Contact Resistance: 20mΩ Max
Operating Temperature:-25℃ to +85℃
MATERIALS:
Contact Material: Phosphor Bronze
Insulation Material: High Temperature Thermoplastic
Finish: Tin Plated
PH0.8, 1.27, 2.0 2.54, 3.96 and 5.08 for options
Soldering type: Straight Dip, Right Angle DIP, Straight SMT, Right Angle SMT.
Sulation Numbers: One layer, double layers.
Row Numbers: One row, two rows, three rows or even four rows.
Material: PBT, Nylon, LCP
