| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | one year |
| Certification: | CE ISO |
| Brand Name: | MAOSU |
| Condition: | New |
| Dimension(L*W*H): | 1500*1350*1150 |
| Weight: | 350KGD |
| Power(W): | 4-55KW |
| Voltage: | 220V/380V/415V |
| Application: | |
| Model Number: | MS |
| Place of Origin: | China (Mainland) |
| Place of Origin: | Henan, China |
| Application: | Puff Snacks |
| Function: | Multifunctional |
| Key Selling Points: | Long Service Life |
| Material: | 304 Stainless Steel/Carbon Steel |
| Power Source: | Electric Power |
| Raw material: | Grain Flour |
| Capacity: | 30-550kg/h |
| Feature: | High Efficiency Easy Operation |
| Advantage: | 20 Years Experience |
Quick Details
Specifications
Descriptions:
1.Snack food extruder is widely used for producing corn snacks, corn puffs, nutrition powder, cereal bar, breakfast cereal, chocolate filled snack etc.
2.It adopt corn, rice, wheat, oat, barley etc as ingredients to make puffed snack. through friction of screw and barrel, the grains are cooked in the extruder. Forming is at the die face cutter.
3.the snack food shape is determined by a combination of the die aperture, including ball, tube, stick, ring, fruit loop, star, wheel and flower etc.All the snack food produced are crispy, easy to be digested and retain nutrients.
Raw materials:
Corn, rice, millet, wheat, oat, barley etc as ingredients.Please note that all the materials should be in powder(flour) or grits form. Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder.
Advantages:
1.Food-grade Stainless steel 304 materials ;
2.Saving labor, a skilled worker could operate 3 equipment ;
3.the cutting structure is very advanced with cutter shaft fixed spring to cut to realize infinitely speed change; the final output product can be Cut freely in different length according to requirement.
4.the Screw is made of special Wear-resisting No38 chromium aluminum molybdenum after tempering, heating and formed, its with wear-resisting and long life.
5.in order to ensure quality and capacity, there is Special pressurization die device. and the electric heating device improves the feed expansion rate.
Parameter:
Model |
Capacity (kg/h) |
Main Power (kw) |
Feed Power (kw) |
Screw Dia (mm) |
Cutting Power (kw) |
MS45 |
30 |
4.0 |
0.4 |
Φ40 |
0.4 |
MS45-A |
50 |
5.5 |
0.4 |
Φ40 |
0.4 |
MS45-B |
60 |
7.5 |
0.4 |
Φ40 |
0.4 |
MS55 |
80 |
7.5 |
0.4 |
Φ50 |
0.4 |
MS65 |
120-150 |
15 |
0.55 |
Φ60 |
0.55 |
MS75 |
200-250 |
18.5 |
0.55 |
Φ70 |
0.55 |
MS85 |
250-300 |
22 |
0.75 |
Φ80 |
0.75 |
MS95 |
400-450 |
37 |
1.5 |
Φ90 |
1.5 |
MS100 |
500-550 |
55 |
1.5 |
Φ100 |
2.2 |
Product Show
