| Weight: | 30 kg |
|---|---|
| Brand Name: | MEIRI |
| CNC or Not: | Normal |
| Type: | Drill Bit Grinding machine |
| Condition: | New |
| Certification: | CE ISO |
| Dimension(L*W*H): | 49*25*26cm |
| Power(W): | 250W |
| Voltage: | 220V 50/60Hz |
| Model Number: | MR-26A |
| Place of Origin: | China (Mainland) |
| Max. Grinding Diameter: | 32 mm |
Quick Details
Specifications
26A can sharpen the top angle (tip angle), back angle (escape angle) and back of the drill bit, easy drilling, easy chip removal.
Compare with 13A, 26A's grinding range is bigger.
Grinding range:(8)13-26(32)mm
Point Angle: 95°-135°
Power: 220V 50/60Hz
Motor: 250W
Speed: 4400RPM
Grinding wheel: CBN (for HSS) or SD (for Tungsten Steel)
Standard equipement:26# fourteen collets. One CBN wheel
Standard grinding range:26# (13-26),optional:8-32
Compare with 13A, 26A's grinding range is bigger.
Grinding range:(8)13-26(32)mm
Point Angle: 95°-135°
Power: 220V 50/60Hz
Motor: 250W
Speed: 4400RPM
Grinding wheel: CBN (for HSS) or SD (for Tungsten Steel)
Standard equipement:26# fourteen collets. One CBN wheel
Standard grinding range:26# (13-26),optional:8-32
