High grade steel is formed to precise tolerances. Quite possibly the last hose reel you will ever need to buy. A weather resistant, TGIC polyester powder-coad paint is melted to the steel in a 400° F cure oven. Containing special agents that prevent scratching and marring, this hardand smooth coating will stay attractive for years. Professional quality. No more tangled hoses! All steel construction. Automatic rewind. Extra large reel diameter to prevent walk-up hose binding. 4-way roller guides and a guide arm that adjusts for any mounting position including floor, pit and ceiling mounting.

Specifications:
Industrial grade steel construction
Hose locks in place during use
Spring powered auto rewind
Machined to floor, wall or ceiling
Corrosion resistant powder coat finish
Full-flow solid brass swivel joint
Multi-position release ratchet and spring fully enclosed and lubricated
Four direction non-snag rollers reduce hose wear
Model
BL7011-25
BL7011-20
BL7011-15
BL7011-10
Hose material
RUBBER HOSE
RUBBER HOSERUBBER HOSERUBBER HOSE
Hose length(FT)
82
655025
Hose I. D
3/8"ID
3/8"ID3/8"ID3/8"ID
Air lntet/Outlet
3/8"
3/8"3/8"3/8"
Working pressure
300PSI
300PSI300PSI300PSI
Outer casing materialSTEELSTEELSTEELSTEEL
Packing Dim
52.5 26 56.5cm
470 210 50052.5 26 56.5cm52.5 26 56.5cm
N. W. /G. W.
18/19KGS
18/19KGS19/20.5KGS18/19KGS
Container
950PCS/20FT, 1925PCS/40FT
551PCS/20FT, 1143PCS/40FT396PCS/20FT, 792PCS/40FT396PCS/20FT, 792PCS/40FT
