Brand Name: | Genius Robotics Zhenkang |
---|---|
Output Speed: | 81 |
Input Speed: | 80 |
Output Torque: | 500Nm |
Gearing Arrangement: | Cycloidal |
Quick Details
Specifications
160E famed provides a widest range of standard and customized solutions for applications in the fields of motion control and mechanical transmission. We supply precision inline planetary gearboxes and right angle planetary gearbox, 90 degree right angle servo motor gearboxes, harmonic drive gearboxes, robot-use RV reducers, grinding precicion rack & gears, servo motor, stepper motor, brushless motor, etc. And our group company also can offer worm gear reducers, gear motors, screw jacks, steering gears, and other related reducer gearboxes and accessories. that means you can get what you want here and will get benefits from our one-stop service that your time and cost will be saved.
Feature
1.Zero Backlash
2.High Tilting Moment Capacity; 142 to 4400 Nm.
3.High Positioning Accuracy <1 arc min.
4.High Positioning Repeatability±15 arcseconds Angular transmission error.
5.High Torsional Stiffness from 8 through 310 Nm/arcmin.
6.High Tilting Stiffness from 142 through 4400 Nm/arc min.
7.High Radial Force from 2800 N to 22500 N.
8.High Axial Force from 4100 N to 35500 N.
Why Choose a Zhenkang Cycloidal Reducer?
High productivity manufacturing requires automation systems that are highly accurate and extremely repeatable. Standard gear products, like planetary gearheads, rarely have the backlash control or torsional rigidity to perform as necessary. this is especially true in robotics, machine tool, medical, communication and some military applications.
There are a few devices available that provide many of the characteristics required for these types of applications. but none provide the torque density, rigidity and backlash control that is available from Spinea through DieQua. with some of the best delivery times in this market, you'll actually be able to take advantage of the high performance features without having to wait for the seasons to change.
RV-20E Working Parameters
Output rotate speed r/min Model |
5 |
15 |
25 |
35 | ||||
Output Torque |
Input Power |
Output Torque |
Input Power |
Output Torque |
Input Power |
Output Torque |
Input Power | |
Nm |
kW |
Nm |
kW |
Nm |
kW |
Nm |
kW | |
20E |
243 |
0.17 |
180 |
0.38 |
152 |
0.54 |
137 |
0.66 |
Note: the rated torque is the output torque when the output rotate speed is at 15r/min.
RV-20E Performance Parameters
Model |
Speed Ratio |
Allowable output speed |
Maximum Backlash |
Allowable acceleration/deceleration torque |
Momentary max allowable torque |
Allowable moment |
Momentary max allowable movement |
Weight |
Efficiency |
Noise | |
Shaft Rotate(R) |
Housing Rotate |
r/min |
Arc.Min |
Nm |
Nm |
Nm |
Nm |
kg |
% |
dB | |
20E |
81 |
80 |
75 |
1 |
450 |
900 |
880 |
1760 |
4.7 |
>80 |
<75 |
105 |
104 | ||||||||||
121 |
120 | ||||||||||
141 |
140 | ||||||||||
161 |
160 |
RV-20E Installation Parameters
Inner hexagon bolt Nominal dimension x pitch(mm) |
Fastening Torque(Nm) |
Fastening Force(N) |
Bolt Requirement |
M6 1.0 |
15.6±0.78 |
13180 |
GB/T 70.1-2000 Intensity class:12.9 Thread requirement: GB/T 1167-1996 |
