| Brand Name: | Genius Robotics Zhenkang |
|---|---|
| Output Speed: | 81 |
| Input Speed: | 80 |
| Output Torque: | 500Nm |
| Gearing Arrangement: | Cycloidal |
Quick Details
Specifications
this design also allows the load to be mounted to the output flange or case. this unit can be piloted on the outer diameter and the case has through hole mounting. An input flange and gasket kit are required for sealing the unit.
Feature
1.Zero Backlash
2.High Tilting Moment Capacity; 142 to 4400 Nm.
3.High Positioning Accuracy <1 arc min.
4.High Positioning Repeatability±15 arcseconds Angular transmission error.
5.High Torsional Stiffness from 8 through 310 Nm/arcmin.
6.High Tilting Stiffness from 142 through 4400 Nm/arc min.
7.High Radial Force from 2800 N to 22500 N.
8.High Axial Force from 4100 N to 35500 N.
RV-20E Working Parameters
Output rotate speed r/min Model |
5 |
15 |
25 |
35 | ||||
Output Torque |
Input Power |
Output Torque |
Input Power |
Output Torque |
Input Power |
Output Torque |
Input Power | |
Nm |
kW |
Nm |
kW |
Nm |
kW |
Nm |
kW | |
20E |
243 |
0.17 |
180 |
0.38 |
152 |
0.54 |
137 |
0.66 |
Note: the rated torque is the output torque when the output rotate speed is at 15r/min.
RV-20E Performance Parameters
Model |
Speed Ratio |
Allowable output speed |
Maximum Backlash |
Allowable acceleration/deceleration torque |
Momentary max allowable torque |
Allowable moment |
Momentary max allowable movement |
Weight |
Efficiency |
Noise | |
Shaft Rotate(R) |
Housing Rotate |
r/min |
Arc.Min |
Nm |
Nm |
Nm |
Nm |
kg |
% |
dB | |
20E |
81 |
80 |
75 |
1 |
450 |
900 |
880 |
1760 |
4.7 |
>80 |
<75 |
105 |
104 | ||||||||||
121 |
120 | ||||||||||
141 |
140 | ||||||||||
161 |
160 | ||||||||||
RV-20E Installation Parameters
Inner hexagon bolt Nominal dimension x pitch(mm) |
Fastening Torque(Nm) |
Fastening Force(N) |
Bolt Requirement |
M6 1.0 |
15.6±0.78 |
13180 |
GB/T 70.1-2000 Intensity class:12.9 Thread requirement: GB/T 1167-1996 |
