Type: | Other |
---|---|
After-sales Service Provided: | Engineers available to service machinery overseas |
Certification: | CE |
Weight: | 180 |
Voltage: | 220V |
Brand Name: | Genius Robotics |
Quick Details
Specifications
More and more laser welding systems have integrated devices such as off - line programming software and weld detection sensors that reduce soldering preparation time and increase productivity.
this off - line programming software works with a variety of measurement sensors to automatically identify different workpieces. It is suitable for production methods with a large number of workpieces.
the robotic laser welding system can also be configured with CAD/CAM offline programming software. the welding program is automatically generated in the software by importing the 3D digital model file of the workpiece, instead of teaching, which can save a lot of time.
Laser welding robot application
Laser welding robot applications inclusive is very wide, used in batteries, electronics, optical communications, automotive, microelectronics, hardware, household appliances, medical equipment, molds, bathroom, super capacitors, motors, electrical, instrumentation, aerospace, solar, glasses, jewelry and so on.
Welding materials involved mainly metal materials,
Such as: stainless steel, aluminum, carbon steel, brass, copper, galvanized sheet, rare metals.
Laser welding robot technical parameter
Laser type | YAG lamp pump laser generator | |
Laser wave length | 1.064μm | |
Maximum power | 300W | 600W |
Single pulse maximum output power | 150J | |
Output stability | ±5% | |
Laser transmission mode | Flexible fiber | |
Power supply | 3 phase AC 380V | |
Maximum input power | 8KW | 16KW |
Size | L750xW1620xH1340 | |
Working table (optional) | Precision electrical slide working table; galvanometer working table; robot device | |
Positioning accuracy | ±0.01mm | |
Cooling system | Internal & external double circulation heat exchange | |
Heat exchange power | 12.5KW | 18KW |
Quantity of fiber transmission branches | 1 ~ 4 | |
Storable laser type | 32 types | |
Video monitoring ( optional ) | High - definition camera + 14 inch monitor | |
Format supported | dwg | |
Weight | 400kg |
Laser Welding Robot Arm Technical Parameter
Distance of 5th axis reaches | 1.44m |
Number of robot body axes | 6 |
Number of external devices axes | 6 |
Continuous rotation axis | 6 |
Repeat positioning accuracy | 0.05mm |
Tcp top speed | 2.1m/s |
Laser type | IPG fiber laser generator |
Laser power(standard/optional) | 500W/1000W |
Power supply | 200-600V, 50/60Hz |
Weight of robot arm | 380kg |
Integrated source | Upper arm 23 channel signal |
Integrated gas source | Upper arm up to 8bar |
