| Brand Name: | Digital Turbine for bitumen flow meter 220v lube oil flow meter |
|---|---|
| Accuracy: | 1.0% |
| Power Supply: | 24VDC/3.6V battery |
| output: | 4-20mA, pulse output,hart,Modbus |
| Medium: | oil/fuel/diesel/food oil/vegetable oil/lubricant oil |
| Model Number: | LWGY |
| Place of Origin: | China (Mainland) |
| Material: | Stainless Steel/SS304/316L |
| Connection: | Flange |
| Pressure: | 1.6MPa, 2.5MPa, 4.0MPa, 6.4MPa, 10MPa |
| Display: | LCD Digital |
| Communication: | RS-485/ Hart |
| Certification: | ISO,CE |
Quick Details
Specifications
the LWGY series turbine flow meter is a new generation of turbine flow meter that has absorbed the domestic and foreign flow meter cash technology and has been optimized and designed. It has the characteristics of simple structure, light weight, high precision, good reproducibility, responsiveness, easy installation and maintenance, and is widely used. In the measurement of closed pipes, it has no corrosion effect with stainless steel 1Cr18Ni9Ti, 2Cr13 and corundum AI2O3, cemented carbide, and has no impurities such as fibers and particles. the kinematic viscosity at operating temperature is less than 510-6m2/s. For kinematic viscosity greater than 510-6m2/s liquid can be used after the liquid calibration of the flow meter. If it is matched with a display instrument with special functions, it can also perform quantitative control and over-alarm alarm, etc. It is an ideal instrument for flow measurement and energy saving.
