| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | one year |
| Brand Name: | MAX HEAVY INDUSTRY |
| Motor Type: | AC Motor |
| Condition: | New |
| Certification: | ISO9000 |
| Weight: | 300KGS-30000KGS |
| Model Number: | 30 |
| Place of Origin: | China (Mainland) |
| Capacity(t/h): | 1000 |
| Power(W): | 15-650 |
| Application: | metallurgy, mining, chemical, cement, construction, refractory materia |
| Type: | Jaw Crusher |
Quick Details
Specifications
Jaw crusher is a type of
Effective and energy conservation crushing machinery. Jaw crusher is main
Applied in all kinds of ore and big block material medium size crushing
Material's hardness should be less than 320Mpa coarse crushing and fine
Crushing are available. this series has a complete range of specifications
Feeding size could be 125mm750mm it's the first choice of
Primary crushing.
Raw Materials:
Granite, marble, basalt, iron Ore, cobble, shale, bluestone, coal, cobblestone, construction material
Application:
Metallurgy, mining, chemical,
Cement, construction, refractory materials, ceramic industry all kinds of ore
and rock with medium hardness medium and fine crushing process Model Feed Opening (mm) Max. Feed size (mm) Range of Discharge Opening(mm) Capacity Speed (r/min) Power Weight Overall Dimension PE-400600 400600 340 40-100 16-60 275 6P 30 7 173017301630 PE-500750 500750 425 50-100 40-110 275 6P 55 12 198020801870 PE-600900 600900 500 65-160 50-180 250 6P 55 17 219022062300 PE-7501060 7501060 630 80-140 110-320 250 8P 110 29 266024302800 PE-9001200 9001200 750 95-165 220-450 200 8P 110 52 338028703330 PE-10001200 10001200 850 195-265 315-500 200 8P 110 55 348028763330 PE-12001500 12001500 1020 150-350 400-800 180 6P 160-220 100.9 420033003500 PEX-2501000 2501000 210 25-60 16-52 330 6P 30 7 156019501390 PEX-2501200 2501200 210 25-60 20-61 330 6P 37 9.7 214016601500 PEX-3001300 3001300 250 20-90 16-105 300 6P 55 15.6 272019501600
(t/h)
(kw)
(t)
(mm)
